Home > Products > 3W 5W 85-265v 3H Steel Housing Ni-Cd Battery Type LED Emergency EXIT Light
3W 5W 85-265v 3H Steel Housing Ni-Cd Battery Type LED Emergency EXIT Light
Click on the image to view the original image
Product： views：23W 5W 85-265v 3H Steel Housing Ni-Cd Battery Type LED Emergency EXIT Light
Branch： EIMOSSI
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-11-19 19:18
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
EIMOSSI
Bulb Type:
LED
Battery Type:
Ni-Cd
Material:
Cold Rolled Steel Sheet
Usage:
LED Emergency EXIT Light
Certification:
CE
Specifications:
3W/5W
Product Name:
85-265v 3H Steel Housing Ni-Cd Battery Type LED Emergency EXIT Light
Input Voltage:
85-265VAC
Function:
Maintained/non-maintained
Installation:
Wall Surface Mounted Fire Led Emergency Lighting
Light Source:
27PCS 2835 LED
Color:
White
Emergency Time:
180 Minutes
Charge time:
24 Hours
Application:
Commercial
Warranty:
2 Year
Supply Ability
Supply Ability:
200000 Unit/Units per Month
Packaging & Delivery
Packaging Details
3W 5W 85-265v 3H Steel Housing Ni-Cd Battery Type LED Emergency EXIT Light
1.package:carton
2.Carton size:0.42*0.41.5*0.23M(0.04CBM)
3.6PCS/Carton
4230pcs for 20GP
Port
zhongshan
Lead Time:
Quantity(Units)1 - 504 >504
Est. Time(days)25To be negotiated
Specification
3W 5W 85-265v 3H Steel Housing Ni-Cd Battery Type LED Emergency EXIT Light
material
steel sheet spray ivory white
rated voltage
220-240VAC~50/60Hz
input power
5W
light source
27 pcs white SMD LED
battery
Ni-Cd 3.6V SC1500MAH
duration time
180 min
Demension
390*190*60mm
Warranty
2 years
Product Description

Product Details

3W 5W 85-265v 3H Steel Housing Ni-Cd Battery Type LED Emergency EXIT Light.

This emergency exit sign light is the cold rolled steel sheet housing+PC diffuser+PET replaceable legend, maintained or non-maintained, wall, side and ceiling mounted.
Product size: 390*190*60mm
Suited for: Indoor
IP Rating: IP20

Product Details

Advanced wide angle white 33 SMD LEDs as a light source.
Efficient driver circuit.
Color Temperature: White
LED lifetime: >50,000 Hrs
Provides excellent viewing distances of 24 meters

SELV classified(outputs LED,batteries,status LED,test switch)
Standard:EN-60598-2-22

Product Details

Long-life, maintenance-free, rechargeable Ni-cd batteries;
Internal solid-state transfer switch automatically connects internal batteries to LED board and LED lamp heads for emergency illumination;
Over-charged and over-discharged protection;
Innovative, Snap-together design for fast and easy installation;


Product Details

Wall, side and ceiling mounted.

Dimension: 390*190*60mm
Package: a bag+inner box for per piece,                                                     6 pcs put into an carton
Package size: 425*415*230mm(0.041CBM)
N.W.: 11KG
G.W.: 12KG
H.S.:94054090.00

Product name:
3W 5W 85-265v 3H Steel Housing Ni-Cd Battery Type LED Emergency EXIT Light
Product size:
390*190*60mm
390*190*60mm
Duration:
3hours
3hours
Light source:
27Pcs SMD LED
27Pcs SMD LED
Operation:
Maintained/Non-maintained
Maintained/Non-maintained
Power source:
85-265VAC~50/60Hz
85-265VAC~50/60Hz
Emergency Lumen
200lm
400lm
Battery:
Ni-cd 3.6v AA800mah
Ni-cd 3.6v SC1500mah
Color Temperature:
White
White
Test:
M10 push on button
M10 push on button
Indicators:
Φ5 LED Green:charge
Φ5 LED Green:charge
Working temperature:
0°C~40°C
0°C~40°C
Recharge period:
24hours
24hours
Average lifetime without any errors:
>5,000 Hrs
>5,000 Hrs
LED lifetime:
>50,000 Hrs
>50,000 Hrs
IP Rating:
IP20
IP20
Suited for:
Indoor
Indoor
