- Type:
- Aviation Obstruction Lights
- Input Voltage(V):
- DC12V,DC24V,DC48V or AC220V
- Lamp Power(W):
- 10
- Lamp Luminous Flux(lm):
- 100
- Lamp Luminous Efficiency(lm/w):
- 120
- CRI (Ra):
- 100
- Color Temperature(CCT):
- Other
- Beam Angle(°):
- 360 Horizontal Beam Angle
- IP Rating:
- IP67
- Certification:
- CE, RoHS
- Emitting Color:
- Red,Green,Yellow(Amber),White
- Lamp Body Material:
- Other
- Base Type:
- Other
- Light Source:
- LED
- Place of Origin:
- Guangdong, China
- Brand Name:
- Annhung
- Light source:
- LED
- Service life of LED:
- ≥100,000hours
- Wind load:
- 80m/s
- Ambient temperature:
- -55℃~+60℃
- Working mode:
- Flashing mode or Steady-burning mode
- International standard:
- IALA
- Overall size(mm):
- 220 by 233
- Installation size:
- 190 by M10
- Supply Ability:
- 1000 Piece/Pieces per Month Marine Lanterns
- Packaging Details
- Plastic bag with paper carton.
- Port
- Hongkong / Shenzhen
AH-LS/P-2 LED Marine Lanterns navigation using for 5 to 8 Nautical Miles
1.Product Name:Marine Lanterns
2.Mode: AH-LS/P-2
3.Standard: IALA
4.Light intensity: 75cd(5nm),150cd(6nm),270cd(7nm),500cd(8nm)
5.Working Mode : Flashing mode or Steady-burning mode
6.Light source: LED
7.Service life of LED: ≥100,000hours
8.Operating voltage: DC12V,DC24V,DC48V or AC220V
9.Light character:option 256 light characters
10.Emitting color:Red,Green,Yellow(Amber),White
Option Function
1. Remote Control Function. Turn on and off lights open place in 3km without obstacle (effective distance) by Remote controller.
2. GPS Syn Function. All Marine Lanterns can flash at the same time by GPS.
3. Adjustable 256 characters.
Product Application
fixed and floating structures
Packaging: Plastic bag with Paper carton .
Delivery: In 2-30 days after payment.
Anhang Technology (HK) Company Limited is a high technology enterprise engaging in research, production, sales and after -sales services for a wide range of Aviation Obstruction Light,Aircraft Warning Light,Helipad Light, LED Marine Lanterns,LED Bulb and Aircraft Warning Sphere.We are a domestic market leader in the field of navigation lights and a supporter of green and safe emissions. Our products are widely used in Civil Airports, Helipads, Communication Towers, Factory,Power Plant Chimneys, Television Tower, Port, Bridges, and High-rise buildings, Buoyage in sea, etc.
All our products are designed and manufactured strictly according to ICAO (International Civil Aviation Organization), FAA (Federal Aviation Administration) and IALA(International Association of Lighthouse Authorities). We are proud to have served customers from all across the world.
After-sales service
1. 2 years full warranty, 5 years maintenance since the purchasing date.
2.Since the purchasing date, full warranty from 1st year to 2nd year, free maintenance cost and material cost.
3.Since the purchasing date, maintenance from 3rd year to 5th year, free maintenance charge.
