Xenon lamp Heliport Beacon
Heliport beacon
Helipad beacon light
Morse code H heliport light
con. compliant with ICAO,FAA,CAAC
This product is used for long-distance visual guidance and does not let helicopter feel glaring.
Main Parameter
| Description | Parameter |
| Mode | AH-HP/B |
| Light intensity | 2500cd |
| Light source | Xenon lamp |
| Operating voltage | AC220V,50/60 Hz(Option voltage) |
| Signal mode | Flashing mode, 4 times in 2 second. |
| Emitting color | White |
| Power consumption | 15W |
| Overall size(mm) | Φ158×410 |
| Installation size(mm) | Φ100×12 |
| Ambient temperature | -55℃~+70℃ |
| Weight | 3kg |
| Protection standard | IP65 |
Compliance
The lights in accordance with ICAO and FAA regulations and CAP437 (offshore helipads)
