Overview
Quick Details
- Type:
- Aviation Obstruction Lights
- Input Voltage(V):
- DC(12-48VDC) or AC(110-240VAC)
- Lamp Power(W):
- 11
- Lamp Luminous Flux(lm):
- 100%
- Lamp Luminous Efficiency(lm/w):
- 120
- CRI (Ra):
- 100
- Color Temperature(CCT):
- Cool White
- Beam Angle(°):
- Horizontal Output 360 degrees
- IP Rating:
- IP66
- Certification:
- CE, RoHS
- Emitting Color:
- Red
- Lamp Body Material:
- Aluminum Alloy
- Base Type:
- Other
- Light Source:
- LED, high intensity LED
- Place of Origin:
- Guangdong, China
- Brand Name:
- Annhung
- Available Colors:
- Red
- International standard:
- ICAO FAA
- Intensity(cd):
- 2000cd±25%
- Vertical Divergence(degrees):
- 3
- Flash Characteristics:
- 20-60 flashes per minute
- Operating Voltage:
- DC(12-48VDC) or AC(110-240VAC)
- Operation Mode:
- Dusk-to-dawn Automatically as standard. 24hours operation as option
- Circuit Protection:
- Integrated
- LED Life Experience(hours):
- >100,000
Supply Ability
- Supply Ability:
- 1000 Piece/Pieces per Month
Packaging & Delivery
- Packaging Details
- Carton
- Port
- Shenzhen
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 100 >100 Est. Time(days) 15 To be negotiated
Product Description
Product performance:
This Medium-intensity Type B Aviation Obstruction Light flashing red color, designed for marking top of obstacle which height is between 45 to 105 meters.
Main-standby mode ensure the obstacle is always marked even one light fail. Because when main top main lamp fail, down standby lamp will turn on automatically
Products adavantages：
Compliance:
**ICAO Annex 14 Volume 1, Sixth edition, 2013, table 6.3 Medium Intensity Type B Obstruction Light
** FAA L-864
Electrical
** CREE ultra high intensity LED as light source saving power consumption and maintenance than incandescent light or halogen lamp
** Power supply available in DC(12-48VDC) or AC(110-240VAC)Physical
** Unique design and UV protected polycarbonate lens for converging light** UV protection Powder coated bright yellow color base make better visibility** Base material is die casting aluminum which has strong corrosion resistance, Shock and Vibrations protection
** Special valve installed beside the base to make sure the air could go through but water is avoid, so that the whole light temperature won’t be high.
System design
** Built-in photocell for day/night operation(dusk to dawn operation)
** Surge and lightning protection
** Main-standby modeOptional
** Alarm contact for remote monitoring
** Infrared LED for pilot using NVG
** GSM cellphone monitoring
** RS485/232 communication part for monitoring
** User adjustable flashing rate(20, 30, 40, 60 flashes/minute)
** GPS synchronizationApplication
AH-MI/DO medium-intensity light is used on the top of the High-rise Building, High Chimney, marking towers (Telecom, GSM, Microwave & TV), High Pole, Tower Crane, Wind Turbine, etc when the obstacle height is 45-105meter, and most time work with low intensity lights installed on the lower place.
Detailed Images
Packing & Delivery
Product more parameters：
Body Material | Polycarbonate (High borosilicate glass as optional) |
Base Material | Powder-coated Die-casting aluminum |
Dimension(mm) | 236 by 236 by 190 |
Weight(kg) | 5 |
Product Life Expectancy | 5 years Plus |
Operating Voltage | DC(12-48VDC) or AC(110-240VAC) |
Humidity | 0%-100% |
Wind Speed | 80m/s |
Waterproof | IP66 |
ICAO | Annex 14 Volume 1,'Aerodrome Design and Operations’ Sixth edition 2013, table 6.3 Medium-intensity Type B Red Obstacle Light |
FAA | L864 |
