- Type:
- Aviation Obstruction Lights
- Input Voltage(V):
- 3.7
- Lamp Power(W):
- 90
- Lamp Luminous Flux(lm):
- 120
- Lamp Luminous Efficiency(lm/w):
- 100
- CRI (Ra):
- 100
- Color Temperature(CCT):
- Cool White
- Beam Angle(°):
- Vertical Divergence(degrees) ≥10
- IP Rating:
- IP68
- Certification:
- CE, RoHS, UL
- Emitting Color:
- Red
- Lamp Body Material:
- PC
- Light Source:
- LED, LED
- Place of Origin:
- Guangdong, China
- Brand Name:
- Anhung
- Available Colors:
- Red, Green, Yellow, White, Blue Red/Green, Yellow/White
- Intensity(cd):
- >25cd
- Vertical Divergence(degrees):
- ≥10
- Flash Characteristics:
- Steady(Flashing mode is optional)
- Operation Mode:
- Solar panel as photocell for day/night operation
- Weight(kg):
- 2.5
- Lamb Body Material:
- Aluminum Alloy
- Base Material:
- Powder-coated Die-casting aluminum
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 100 >100 Est. Time(days) 15 To be negotiated
AH-SA-C Solar Airfield Light is specially used on permanent airport/heliport where cable power is not convenient or temporary helipad.Wireless remote control is optional function for this light.User could turn on/off light within 3-4km without obstacle between light and controller.Fragile coupling need to be paid separately if needed.
** ICAO Annex 14
** FAA AC 150/5345
** CAP 437
LED as light source saving power consumption and maintenance, 95% less power than equivalent incandescent light.
Integrated design, enabling a rugged and completely waterproof seal capable of prolonged and deep immersion (IP68).
PC housing, UV resistance, shockproof and corrosion proof.
Bird deterrent spike
Powder coated die casting aluminum base Built-in mono crystalline silicon solar panel, conversion efficiency is
better than poly crystalline silicon.
ON/OFF button interface located under base
Light Turn on at night and closed at daytime automatically
Optional
User-adjustable operation mode to toggle between dusk-till-dawn & 24hr operation
External charger
Wireless remote control
NVG - compatible infrared (IR) LED
GPS sync flashing
Pilot to ground remote control(VHF radio control)
Application
Airport, Touchdown and Lift- off area ( TLOF) , Final Approach and Take- off area ( FATO) , Taxiway lighting, Runway edge lighting, Portable or expedited airfield lighting, Threshold lighting
Helipad taxiway
Emergency operations
| Light Characteristics | |
| Light Source | LED |
| Available Colors | Red, Green, Yellow, White, Blue,Red/Green, Yellow/White |
| Intensity(cd) | >25cd |
| Horizontal Output(degrees) | 360 |
| Vertical Divergence(degrees) | ≥10 |
| Flash Characteristics | Steady(Flashing mode is optional) |
| Operation Mode | Solar panel as photocell for day/night operation |
| LED Life Experience(hours) | >100,000 |
| Solar Characteristics | |
| Operating Voltage | 3.7 |
| Solar Module Type | Mono crystalline Silicon |
| Circuit Protection | Integrated |
| Charging Regulation | Microprocessor controlled |
| Physical Characteristics | |
| Lamb Body Material | Aluminum Alloy |
| Base Material | Powder-coated Die-casting aluminum |
| Installation Size | 190×190×M10 |
| Dimension(mm) | 220×220×233 |
| Weight(kg) | 2.5 |
| Product Life Expectancy | Average 5 years |
| Environmental Factors | |
| Ambient Temperature(℃) | -55~70 |
| Humidity | 0%-100% |
| Wind Speed | 80m/s |
| Waterproof | IP68 |
| Compliance | |
| ICAO | Annex 14 Volume 2 Heliports 5.3 |
| FAA | AC 150/5390-2B Heliport Design Guide |
| Options Available | Wireless remote control, Pilot to ground remote control(VHF radio control) |
| External battery charger, Dusk-till-dawn & 24hr operation adjustable switch | |
| NVG - compatible infrared (IR) LED |
