- Type:
- Aviation Obstruction Lights
- Input Voltage(V):
- DC(12-48VDC) or AC(110-240VAC)
- Lamp Power(W):
- 10
- Lamp Luminous Flux(lm):
- 100%
- Lamp Luminous Efficiency(lm/w):
- 120
- CRI (Ra):
- 100
- Color Temperature(CCT):
- red
- Beam Angle(°):
- 360 degree Horizontal Beam Angle
- IP Rating:
- IP66
- Certification:
- CE, RoHS
- Emitting Color:
- Red
- Lamp Body Material:
- Aluminum Alloy
- Base Type:
- Other
- Light Source:
- LED
- Place of Origin:
- Guangdong, China
- Brand Name:
- Annhung
- Service life of light source:
- 100,000hours
- Weight:
- 3.5Kg
- International standard:
- ICAO Medium Intensity FAA L-864
- Vertical Divergence(degrees):
- 3
- Operation Mode:
- Dusk-to-dawn Automatically as standard. 24hours operation as option
- Circuit Protection:
- Integrated
- Body Material:
- Polycarbonate (High borosilicate glass as optional)
- Base Material:
- Powder-coated Die-casting aluminum
- Humidity:
- 0%-100%
- Supply Ability:
- 1000 Piece/Pieces per Month
- Packaging Details
- paper carton 1 piece/box
3-15 days
- Port
- HongKong,Shenzhen
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 100 >100 Est. Time(days) 7 To be negotiated
Medium-intensity Type B L864 Aviation Obstruction Light Aviation Light
Aviation Obstruction Light
Aviation Warning Light
Aircraft Obstruction Light
Aviation High Building Warning Light
compliant with ICAO,FAA
Scope of Application
This 2000cd Medium-intensity Type B L864 Aviation Obstruction Light flashing red color, designed for marking top of obstacle which height is between 45 to 105 meters.
Ultra high intensity CREE LED is used for the light source ensure the long life experience and good performance.Self-designed lens converging light to very small vertical divergence 3° make it totally compliance with ICAO standard. It"s your better choice.
Main Parameter
| Description | Parameter |
| Light Source | CREE high intensity LED |
| Light intensity | 2,000cd ±25% |
| Flash rate | 20-60 flashes per minute |
| Operating voltage | AC220V (option voltage,eg.AC120V,AC110V,DC48V) |
| Power(W) | 10 |
| Overall size(mm) | 236*236 *161 |
| Installation size(mm) | 190*190*θ12 |
| Body Material | Polycarbonate (High borosilicate glass as optional) |
| Base Material | Powder-coated Die-casting aluminum |
| Available color | red |
| Wind load | 80m/s |
| Protection standard | IP66 |
Electric
CREE ultra high intensity LED as light source saving power consumption and maintenance than incandescent light or halogen lamp
Power supply available in DC(12-48VDC) or AC(110-240VAC)
Physical
Unique design and UV protected polycarbonate lens for converging ight
UV protection Powder coated bright yellow color base make better visibility
Base material is die casting aluminum which has strong corrosion esistance, Shock and Vibrations protection
Special valve installed beside the base to make sure the air could go through but water is avoid, so that the whole ight temperature won’t be high. Improve waoking performace.
System design
Built-in photocell for day/night operation(dusk to dawn operation)
Surge and lightning protection
Optional
♦ Alarm contact for remote monitoring
♦ GSM cellphone monitoring
♦ User adjustable flashing rate(20, 30, 40, 60 flashes/minute)
♦ GPS synchronization
Application
AH-M-B1 medium-intensity light is used on the top of the High-rise Building, High Chimney, marking towers (Telecom, GSM,Microwave & TV), High Pole, Tower Crane, Wind Turbine, etc when the obstacle height is 45-105meter, and most time work with low intensity lights installed on the lower place.
ICAO Annex 14 Volume 1, Sixth edition, 2013, table 6.3 Medium Intensity Type B Obstruction Light
FAA L-864
