Click on the image to view the original image
- Type:
- Aviation Obstruction Lights
- Input Voltage(V):
- 220VAC
- Lamp Power(W):
- 90
- Lamp Luminous Flux(lm):
- 120
- Lamp Luminous Efficiency(lm/w):
- 100
- CRI (Ra):
- 120
- Color Temperature(CCT):
- Cool White
- Beam Angle(°):
- Vertical Divergence(degrees) ≥10
- IP Rating:
- IP65
- Certification:
- CE, RoHS
- Emitting Color:
- Red
- Lamp Body Material:
- Aluminum
- Base Type:
- E27
- Light Source:
- LED
- Place of Origin:
- Guangdong, China
- Brand Name:
- Anhung
- Operation Mode:
- Dusk-to-dawn Automatically as standard. 24hours operation as option
- Body Material:
- Polycarbonate
- Base Material:
- Die-casting aluminum
- Power(W):
- 2.5
- Circuit Protection:
- Integrated
- Weight(kg):
- 0.3
- Product adavantages:
- Unique designed PMMA lens
- Installation:
- 3/4inch thread hole
- Compilance:
- FAA L810
- Supply Ability:
- 1000 Piece/Pieces per Month
- Packaging Details
- Six sides build in foam carton
- Port
- Shenzhen
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 100 >100 Est. Time(days) 15 To be negotiated
This 25cd aviation obstruction light is a steady burning emmiting red color designed for marking top of obstacle that do not exceed 45 meters in height. (High building, tower, chimney) Products" performance can be customized for diferrent requirements.
Products advantages:
l 3 high power CREE LED, make sure LED keep bright while use. better protect your buildings.
l Power supply in DC(48V)& AC(110-240VAC), the light could work normally when input 48VDC/110VAC/240VAC
Bird deterrent spike on top
Unique designed PMMA lens for converging light and good transparency
High translucency and anti-UV polycarbonate cover could use 3-5years without yellowing
UV protection Powder coated bright yellow color base make better visibility and also long life in harsh environments()
Base material is die casting aluminum which has strong corrosion resistance, Shock and Vibrations protection
3/4inch thread hole make pole installation easy
Safety chain connected with base, the PCB won’t fall while installation
No screw fix type - just twist, the cover will be fixed tightly
We try our best to do best quality products.
System for yourchoice:
Built-in photocell for day/night operation(dusk to dawn operation, automatically turn on when background luminance is below 50cd/m2
Steady/20FPM/30FPM/60FPM DIP switches on PCB
Surge and lightning protection
Optional Function: Alarm contact(NO COM NC)for remote monitoring
Infrared LED for pilot using NVG
Application
l AH-LI-B2 low-intensity light could be used alone on the top of the High-rise Building, High Chimney, marking towers (Telecom, GSM, Microwave & TV), High Pole, Tower Crane, Wind Turbine, etc when the height is lower than 45m.
l When obstacle object is higher than 45m, AH-LI/B2 can be used with Medium-intensity or high-intensity obstruction light to indicate hazardous obstructions with a steady red safety light.
Product dimension:
Contact us:
Delivery time:
We are specialized enterprise focusing on research, production, sales and after-sales service of aviation obstruction light,Our products are patented and also have passed CE, ICAO, ISO9001, UL94.
