Overview
Quick Details
- Type:
- Aviation Obstruction Lights
- Input Voltage(V):
- AC 110V-240V
- Lamp Power(W):
- 30
- Lamp Luminous Flux(lm):
- 100%
- Lamp Luminous Efficiency(lm/w):
- 120
- CRI (Ra):
- 100
- Color Temperature(CCT):
- Cool White
- Beam Angle(°):
- Vertical Divergence 3-7 degrees
- IP Rating:
- IP67
- Certification:
- CE, RoHS
- Emitting Color:
- White
- Lamp Body Material:
- Aluminum Alloy
- Base Type:
- Other
- Light Source:
- LED
- Place of Origin:
- Guangdong, China
- Brand Name:
- Annhung
- Weight:
- 9Kg
- Operation Mode:
- 24hours operation, 3 different modes
- LED Life Experience(hours):
- >100,000
- Body Material:
- Polycarbonate (Tempered glass as optional)
- Better visibility:
- Powder coated bright yellow
- Ligh System:
- Surge and lightning protection
- Optional function:
- RS485 communication part for monitoring
Supply Ability
- Supply Ability:
- 1000 Piece/Pieces per Month
Packaging & Delivery
- Packaging Details
- Six side build in carton
- Port
- HongKong,Shenzhen
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 100 >100 Est. Time(days) 15 To be negotiated
Product Description
Usage
This 20000cd High-intensity Type A Aircraft warning Light flashing white color 24 hours and designed for marking top of obstacle that exceed 150 meters in height. Compliance ICAO standard.
Ultra high intensity CREE LED is used for the light source ensure light’s long life experience and good performance.Self-designed reflection board ensure less LED could emitting brighter light and save your power same time.
Product overview:
Compliance:
**ICAO Annex 14 Volume 1, Sixth edition, 2013, table 6.3 High Intensity Type A Obstruction Light
**FAA L-856
Electrical
CREE ultra high intensity LED as light source saving power
Power supply available in DC(48V) or AC(110V, 240V)
Physical
Unique design and UV protected polycarbonate lens for converging light and saving LED power
UV protection Powder coated bright yellow color base make better visibility
Base material is powder coated die-casting aluminum which has strong corrosion resistance, Shock and Vibrations protection
Special valve installed beside the base to make sure the air could go through but water is avoid, so that the whole light temperature won’t be high to destroy the light System design
Built-in photocell for day/twilight/night operation
Surge and lightning protection.We could design for different customers.
Optional
Alarm contact for remote monitoring
Infrared LED for pilot using NVG
GSM cellphone monitoring
RS485 communication part for monitoring
User adjustable flashing rate(40, 50, 60 flashes/minute)
GPS synchronization
Detailed Images
Product Application:
AH-HI-A0 High-intensity 20000cd obstacle warning light is used on the top of the High-rise Building, High Chimney,marking towers(Telecom,GSM,Microwave & TV), High Pole, Tower Crane, Wind Turbine, etc when the obstacle height is more than 150meter, and most time work with low intensity lights & medium intensity light installed on the lower place. It's used for warning the airplanes where is obstacle.
Packing & Delivery
Detail parameter:
Light Source | CREE high intensity LED |
Available Colors | White |
Intensity(cd) | 200,000cd±25%(Daytime), 20,000cd±25%(Twilight), 2,000cd±25%(Night) |
Flash Characteristics | 40-60 flashes per minute |
LED Life Experience(hours) | >100,000 |
Operating Voltage | DC(48VDC) or AC(110, 240V) |
Average Power(W) | 30W |
Body Material | Polycarbonate (Tempered glass as optional) |
Base Material | Powder coated die-casting aluminum |
Weight(kg) | 9 |
Product Life Expectancy | 5 years Plus |
Waterproof | IP67 |
FAA | L-856 |
Options Available | Powder-coated color, GSM Monitoring |
NVG(Night Vision Goggles) compatible LED | |
GPS Sync Flashing, Dry Contact alarm(NO COM NC) | |
User adjustable flashing rate (40, 50, 60) |
