Overview
Quick Details
- Type:
- Aviation Obstruction Lights
- Input Voltage(V):
- 48VDC
- Lamp Power(W):
- 100
- Lamp Luminous Flux(lm):
- 2000
- Lamp Luminous Efficiency(lm/w):
- 120
- CRI (Ra):
- 120
- Color Temperature(CCT):
- Cool White
- Beam Angle(°):
- Horizontal Output(degrees) 360
- IP Rating:
- 8IP65
- Certification:
- BV, CE, RoHS
- Emitting Color:
- White
- Lamp Body Material:
- Aluminum Alloy
- Base Type:
- Powder coated die-casting aluminum
- Light Source:
- LED
- Place of Origin:
- Guangdong, China
- Brand Name:
- Anhuang
- Operation Mode:
- 24hours operation, 3 different modes
- LED Life Experience(hours):
- >100,000
- Circuit Protection:
- Integrated
- Body Material:
- High borosilicate glass
- Weight(kg):
- 8
- Product Life Expectancy:
- 5 years Plus
- Adjustable Flash:
- 40FPM(Others are optional)
- Flash Characteristics:
- 40FPM(Others are optional)
- lamp replacement.:
- "Safe plug" lamp holder
- Aotomatic operation:
- Built-in photocell
Supply Ability
- Supply Ability:
- 1000 Piece/Pieces per Month
Packaging & Delivery
- Packaging Details
- Six sides build in foam carton
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 100 >100 Est. Time(days) 3800 To be negotiated
Product Description
This High-intensity Type A Aviation Obstruction Light flashing white color 24 hours and designed for marking top of obstacle that exceed 150 meters in height. Compliance ICAO standard.
Incorporates the benefits of advanced xenon strobe and system control technologies to meet the challenges of the most demanding applications. Meet your requirements better.
Cmpliance
**ICAO Annex 14 Volume 1, Sixth edition, 2013, table 6.3 High Intensity Type A Obstruction Light
**FAA L-856
Electrical
High-quality Xenon Lamp with 108times long lamp life, low cost and low power consumption.
Power supply available in DC(48V) or AC(110V, 240V). Make you relax.
Physical
Built-in photocell for day/twilight/night operation
Surge and lightning rotection
System design
Uses AH special technology for the ignition of xenon lamps, hold for
long lamp life and very low UV and ozone emission
“Safe plug” lamp holder for easy lamp replacement.
Optional Function
♥ Alarm contact for remote monitoring
♥ GSM cellphone monitoring
♥ RS485 communication part for monitoring
♥ User adjustable flashing rate(40, 50, 60 flashes/minute)
♥ GPS synchronization
Application
AH-HI-D High-intensity light is used on the top of the High-rise Building, High Chimney, marking towers (Telecom, GSM, Microwave & TV), High Pole, Tower Crane, Wind Turbine, etc when the obstacle height is more than 150meter, and most time work with low intensity lights & medium intensity light installed on the lower place. It can protect your buildings best and compliance ICAO FAA standard.
Detailed description:
Light Source | Xenon |
Available Colors | White |
Intensity(cd) | 200,000cd±25%(Daytime), 20,000cd±25%(Twilight), 2,000cd±25%(Night) |
| Horizontal Output(degrees) | 120 |
| Flash Characteristics | 40FPM(Others are optional) |
| Mounting | θ190×θ12 |
| Dimension(mm) | 236×236×270 |
| Product Life Expectancy | 5 years Plus |
| Body Material | High borosilicate glass (Tempered glass as optional) |
| Base Material | SUS304 stainless steel shell |
| Humidity | 0%-100% |
| Weight(kg) | 8 |
| Wind Speed | 80m/s |
| Waterproof | IP65 |
| FAA | High-intensity Type B White Obstacle Light L857 |
| Options Available | NVG(Night Vision Goggles) compatible LED |
| GSM Monitoring | |
| GPS Sync Flashing | |
| Dry Contact alarm(NO COM NC) | |
| User adjustable flashing rate (40, 50, 60) |
We are specialized enterprise focusing on research, production, sales and after-sales service of aviation obstruction light, and have more than 8 years manufacturing experience for clients from whole world.Our products performance can be customized for different projieces, if you are intersested, contact me now!
