Wireless 9V Battery Operated Smoke Detector
General Description:
OPERATION:
The smoke alarm is operating once a fresh battery is installed and testing is complete. When products of combustion are sensed, the unit sounds a loud 85db pulsating alarm until the air is cleared.
FLASHING LED LIGHT:
This smoke alarm is equipped with a flashing red indicator light. The light is located above the test button and will flash every 40-50 seconds to indicate that the smoke alarm is operating.
SMOKE SENSING CHAMBER OPERATION:
This alarm will “chirp” if any ofthe components in the smoke sensing chamber fail. This chirp will occur between the flashes of the red LED indicator light. (If the chirp occurs at the same time as the red LED flash, see Section 6 for low battery information).
Parameters
 | Power Source: | 9V Battery (included) |
| Standby Current: | less than 10uA | |
| Alarm Current: | less than 20mA | |
| Audio Alarm: | greater than 85dB at 3m | |
| Temperature Range: | 32°F to 104°F (0°C to 40°C) | |
| Humidity Range: | up to 90% relative humidity (RH) | |
| Sensor: | up to 91% relative humidity (RH) | |
| Size: | 4"in diameter × 1.28" depth | |
| Weight: | 0.2lbs | |
| Interconnects: | No | |
| Warranty: | 1 year limited | |
| Signage Number: | ROHS8.807.326 |
Shenzhen Asenware Test And Control Technology Co., Ltd was set up in 2006, our headquarters is in London of UK. Now Asenware is an international group company in BMS and NDT industries.
We are a technology oriented company that devotes to NDT(Non Destructive Test) and BMS(Building Management System) industries.
We have an experienced R&D team to design special electric product for test and control usage.
Our aim "Try all our best offer our customer satisfied items and service
1)Sample oder is welcomed to test the quality.
2 ) Flexible technicals adjusting as per customer" s special request.
3) Answer your enquiries, questions and emails in 24 hours
4) Direct control on material, testing, quality, leadtime etc.
