Asenware 2 wire fire alarm flame detector,ir UV flame detector
Introduction for fire alarm system
- AW-CFP2166 series conventional fire alarm panel is designed based on EN54 part 2&4 standard.
- It is modularized design, the panel can extend from 1 zone to 32 zones easily.
- It has 2 level control mode by a lock
- It has 24VDC and 5VDC power supply output.
- It has FIRE and FAULT signal output.
- It has 2 general sounders output.
- Each zone has 1 circuit detectors input .
- Each zone can be disable by a button.
- It has RESET button to reset the panel.
- It has SILENCE button to stop BUZZER and SOUNDERS.
- It has EVACUATE button to start a manual fire alarm immediately.
- It has battery low protection function, when battery voltage lower than 21VDC, battery will be cut off automatically until the mains power is on.
- It has an optional GSM module for fire alarm by SMS
Specifications for uv flame detector
| Operating Voltage Range | 12 to 30 VDC Volts |
| Standby Current | ≤10 mA @ 24 VDC |
| Alarm Current | ≤30 mA @ 24 VDC |
| Spectrum | 180~290nm |
| Detection Angle | 110 degree |
| Detection Sensitivity with 2Kg ethanol ) | Grade I, 25m flame (Container 33cmX33cm,Height 5cm |
| Relay Contact Load | 1A,DC24V |
| Normal Status | LED blinking in 5 seconds interval |
| Alarm Status | LED lit steady |
| Protection rating | IP 32 |
| Operating Humidity Range | 10% to 93% Relative Humidity, Non-condensing |
| Operating Temperature Range | -10°C to 50°C (14°F to 122°F) |
| Height | 1.8"(45 mm) installed in Base |
| Diameter | 4.0"(103 mm) |
| Weight | 5.4 oz. (153g) |
