Fire Alrm System Addressable Input Module:
Addressable Input Module Introduction:
The AW -AIO2188-IN Intelligent input module (AW-AIO2188-IN module for short) is used with AW - AFP2188,a two-bus fire alarm control panel. I t can be connected with a conventional smoke detector, a conventional heat detector, a conventional manual call point, a conventional hooter/horn and some other equipment. After the said equipment starts to operate, the alarm signal output will be sent by the AW-AIO2188-IN module to the fire alarm control panel through a signal bus to give a fire alarm.
Addressable Input Module Featrures:
1. Mode of operation: Nonpolar two- wire system
2. Quiescent current: 3. Action current: 4. Operation indicator: The inspection indicator will blink once about every 12 seconds in the inspection status
or remain lit in the operation status.
5. Operating environment: Temperature: - 10 °C~ 50 °C ; relative humidity: ≤ 95% (40 °C± 2 °C , without condensation)
6. Terminal load: 4.7K resistance
7. External dimensions: 86×86× 40( mm)
8. Weight: about 119g
9. Executive standard: GB16806-2006
