household conventional 2 wired 1 loop 1 zone fire panel
General description: Best household conventional 2 wired 1 loop 1 zone fire panel
1. This fire panel designed based on EN54 part 2&4 standard.
2. Modularized design which can extend from 1 zone to 32 zones easily.
3. The fire panel has 2 level control mode by a lock
4. It has 24VDC and 5VDC power supply output.
5. It has FIRE and FAULT signal output.
6. It has 2 general sounders output.
7. Each zone has 1 circuit detectors input .
8. Each zone can be disable by a button.
9. Has RESET button to reset the panel.
10. Has SILENCE button to stop BUZZER and SOUNDERS.
11. It has EVACUATE button to start a manual fire alarm immediately.
12. It has battery low protection function, when battery voltage lower than 21VDC, battery will be cut off automatically until the main power is on.
13. The fire panel has an optional GSM module for fire alarm by SMS .
14. It is economic, user-friendly and easy maintenance.
Best household conventional 2 wired 1 loop 1 zone fire panel Best household conventional 2 wired 1 loop 1 zone fire panel
| Parameters of fire panel | |
| Model No. | AW-CFP2166-01 |
| Number of circuit | 1 |
| Total output current limited | 500mA @ 240VAC |
| Mains supply voltage | 110VAC or 240VAC |
| Internal power supply | 27.2VDC |
| Dimensions(mm) | 272X200X75mm |
| Weight (without batteries) | 4kg |
| Weight (with batteries) | 5.8kg |
1. Asenware is a professional manufacturer of fire alarm systems for 10 years .
2. Our main producst: Addressable / Conventional fire alarm control panel , smoke detector , heat detector , bells etc.
3. Have an experienced R&D team to design special electric product for test and control usage.
1. Sample oder is welcomed to test our quality.
2. OEM,ODM service offer
3. 1 year warranty and warmly after sales-service
4. Welcome to visit our factory
Best household conventional 2 wired 1 loop 1 zone fire panel Best household conventional 2 wired 1 loop 1 zone fire panel
Payment terms : T/T L/C Western union .
Delievry time : Usually about 3 to 5 days .Bulk order will last ship out in three weeks .
Certificate : CE , LPCB , ISO9001
Technical support : Yes
