electric fire alarm system control panel
Any question,contact sales skype Asenware.sales09
Specification of adressable fire cotrol panel AW-AFP2100
32-bit MCU
2-wire communication between detector/module
Each detector sensitivity adjustable
Field-programmable with PS/2 standard PC keypad and mouse
7.4" LCD back-lit display
Windows menu and interface
Chinese or English interface and panel display
CF card duplicate or reset system setup file and history file to facilitate maintenance
Communicate with PC via USB
Single point start/stop of module (Menu operation)
Single point test of detector/module
Zone, building or floor display
CRT visually display the location of fire and trouble
Eleven users each with a password and selectable access levels
Field software upgrade
20 JB-QBL-2100 peer-to-peer, long-distance optical fiber transmission network via CAN communication transform module
Flexible collocation by modularized combination
Standards that apply
GB 4717-93 "General Technical Conditions for Fire Alarm Control Units"
GB 16806-1997"General Technical Conditions of control for Fire Protection Equipment"
CE certification
Capacity of addressable fire control panel AW-AFP2100
Each I/O-board has two loops, with 198 alarm/control points of each loop(Max. control points-99), the capacity of each I/O-board: 2x198=396(points);
Each JB-QBL-2100 can connect maximum 3 I/O-boards, the capacity of each JB-QBL-2100: 3 x 396 = 1188(points). Over 1188 points, the wall mounted panel turn to cabinet panel, eahc cabinet panel can connect maximum 40 I/O-boards: 40*396=15840(points).
Peer-to-peer with max. 20 JB-QBL-2100, system capacity: 20 x 15840 = 316800 (points).
Multi-line Integrated Control/Monitoring capacity: Each JB-QBL-2100 wall mounted panel can have maximum 4000 points.
Bus integrated control capacity: Each JB-QBL-2100 wall mounted panel can have maximum 4000 points.
Addressable fire control panel AW-AFP2100 photo and accessories details,
Packaing: regular packing or customized packing
Shipping:DHL,UPS,etc
1.Sample oder is welcomed to test our quality.
2.OEM,ODM service offer
3.1 year warranty and warmly afterservice
4.welcome visit our factory
Shenzhen Asenware Test And Control Technology Co., Ltd was set up in 2006,our headquarters is in London .
Now Asenware is an international group company in BMS and NDT industries.
We are a technology oriented company that devotes to NDT(Non Destructive Test) and BMS(Building Management System) industries.
We have two factories : one factory is in Shenzhen city for BMS products, and the another is in Dandong city for NDT X-ray products.
We have an experienced R&D team to design special electric product for test and control usage.
We try all our best to offer our customer satisfied products.
Payment terms :T/T L/C Western union .
Delievry time :usually about 3 to 5 days .Bulk order will last ship out in three weeks .
Certificate :CE LPCB ISO9001
Technical support :yes
