Building Towers ICAO Certified White Flashing medium intensity Beacon dubai civil aviation aircraft warning light

Click on the image to view the original image

Product：	views：4Building Towers ICAO Certified White Flashing medium intensity Beacon dubai civil aviation aircraft warning light
Branch：	CM
Type：	Aviation Obstruction Lights
Size：	32X32X27 cm
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 18:39

Product Details

Overview

Quick Details

Type:: Aviation Obstruction Lights

Input Voltage(V):: AC90-AC260V

Lamp Power(W):: 30

Lamp Luminous Flux(lm):: 1

Lamp Luminous Efficiency(lm/w):: 1

CRI (Ra):: 1

Color Temperature(CCT):: Cool White

Beam Angle(°):: 360

IP Rating:: IP65

Certification:: BV, CCC, SASO

Emitting Color:: White

Lamp Body Material:: Aluminum Alloy

Base Type:: Others

Light Source:: LED

Place of Origin:: China

Brand Name:: CM

Standard:: FAA,ICAO Standard

Operating voltage:: AC220V (Other available)

Power consumption:: ≤30W

Flashing frequency:: 20~60times/min

Light source:: White LED

Light intensity:: 2000~20000cd(±25%)

Lifespan:: >100,000hours

Beam angle:: 360

Method of synchronization:: GPS

Ingress protection:: IP65

Packaging & Delivery

Selling Units:: Single item

Single package size:: 32X32X27 cm

Single gross weight:: 8.0 kg

Package Type:: Carton

Lead Time:

Quantity(Piece)	1 - 50	>50
Est. Time(days)	15	To be negotiated

ICAO Certificate

Application

Widely used in various fields of the Air Force, civilian airports and obstaclefree airspace, helipads, iron tower, chimney, ports, wind power plants, bridge and city high-rise buildings where require aviation warning.
Usually used above 45m and less than 150m buildings, could use alone, also could use with Medium OBL type B and Low intensity OBL type B together.

Products Description

Key Feature

● Cover of the light adopts PC with anti-UV which is high efficiency light transmission up to 90%, quite high impact resistance and fits the bad environment very well.

● House of the light is made of aluminum alloy and painted by spraying plastics, the structure is high strength, resistance to corrosion.

● Use the special optical reflector design, the visual range further, angle more accurate, no light pollution.

● Light source adopts import high quality LED, lifespan up to 100,000 hours, low power consumption, energy efficiency and environmental protection.

● Based on the single chip computer control, automatic identification sync signal, do not distinguish the main light and auxiliary light, and also could be controlled by the controller.

● Same power supply voltage with synchronous signal, integrate in power supply cable, eliminate the damage by error installation caused.

● Used the photosensitive probe fit for the natural light spectrum curve, automatic control light intensity level.

● The circuit of the light has surge protection, so that the light is suitable for a harsh environment.

● Integral structure, protection level of Ip65.

● GPS synchronizing function is available.

Product Paramenters

Standard	FAA，ICAO Standard	Light source	White LED
Operating voltage	AC220V (Other available)	Light intensity	At day: 20,000cd White Color
Power consumption	≤30W	Light intensity		At night:2000cd White Color
Flashing frequency	20～60times/min	Lifespan	＞100,000hours
Emitting color	White	Method of synchronization	Same power supply voltage signal mode
Beam angle	360° horizontal beam angle	Method of synchronization		GPS
Beam angle		3° vertical beam spread	Ingress protection	IP65
Overall size(mm)	Ф268mm×206mm	Lightning protection level	10KA
Installation size(mm)	166mm×166 mm -4×M10	Light controlled sensitivity	100Lux
Operating temperature	-40℃～55℃	Net weight	7 kg
