- Type:
- Aviation Obstruction Lights
- Input Voltage(V):
- DC12V(Solar powered)
- Lamp Power(W):
- 10
- Lamp Luminous Flux(lm):
- 2000cd
- Lamp Luminous Efficiency(lm/w):
- 1
- CRI (Ra):
- 1
- Color Temperature(CCT):
- Red
- Beam Angle(°):
- 360 Degree
- IP Rating:
- IP65
- Certification:
- CE, RoHS
- Emitting Color:
- Red
- Lamp Body Material:
- Aluminum Alloy
- Base Type:
- 2G11
- Light Source:
- LED, Red LED
- Place of Origin:
- Hunan, China
- Brand Name:
- CK
- Products name:
- single solar power obstruction light
- Power Consumption:
- <10w
- Flashing frequency:
- Flash
- Operating Voltage:
- DC12V(Solar powered)
- Light Intensity:
- 2000cd
- Life Span:
- 100,000hours
- Beam Angle:
- 360° horizontal,more than 3° vertical beam spread
- Overall Size:
- 255mm*255mm*515mm
- wind loading rating:
- 80m/s
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 26X26X54 cm
- Single gross weight:
- 19.5 kg
- Package Type:
- Carton box
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 20 21 - 50 >50 Est. Time(days) 21 28 To be negotiated
1.Lamp shade of the light adopts PC with anti-UV which is high efficiency light transmission up to 90%, quite high impact resistance and fit the bad environment very well.
2.The aluminum alloy base with painting by spraying plastics, the structure is high strength, resistance to corrosion.
3.Light source adopts LED with long lifespan up to 100,000hrs, lower power consumption controller and high efficiency.
1.Synchronized Flashing Units Can"t work Simultaneously
A.Monitor Function Type Requires Power Line seperate from signal line,the power circuit of each unit can be independently connected,pls check signal circuit was connected by corresponding color when ensure power supply works normally.
B.Check if there"s short circuit or leakage phenomenon with the signal circuit after excluding the condition above.
2.Light-operated switch can"t work normally
A.The Unit can"t work at day: Pls check if the light-operated detector is closed over by dust;
B.The Unit can"t work at night: Pls check if light-operated detector is influenced by direct light or strong reflective light;
C.Testing the unit at day: Most of customers test the unit by Closing over the light-operated detector using their hands.Since the strong Radiation of sunshine,the light-operated function can"t work.The proper method is using 3 layers of black opacity adhesive tapes.
3.Are you the Manufactory or Trading?
Our company is professional Manufactory to produce the Aviation Obstruction light.
4.What Kind of Package you choose?
As usual,we use the Carton Box; If delivery by sea,we will use the Wooden case to pack.
Any question for product,Pls contact with us!
