Click on the image to view the original image
- Place of Origin:
- Zhejiang, China
- Brand Name:
- CMP
- Model Number:
- MP019S/F11
- Protection Level:
- IP67,IK10
- Max. Current:
- 5A
- Max. Voltage:
- 250V AC/DC
- Installation diameter:
- 19mm
- The Body Material:
- Stainless steel or Copper plated chrom
- Electrical Life:
- 200,000 cycles
- Mechanical Life:
- 100,0000 cycles
- Contact Material:
- Silver Plated
- The head:
- Flat,Ball,Convex
- Contact Configuration:
- 1NO 1NC or 2NO 2NC
- Operation Type:
- Momentary or Latching
- Product type:
- 3 pin push button switch (1NO1NC)
- Supply Ability:
- 100000 Piece/Pieces per Week 3 pin push button switch
- Packaging Details
- push button switch waterproof Stand Exported Packing:
inner bubble box--- inner box---carton (or by your request.)
Size of CTN: 29*23*31 cm
400PCS/CTN
- Port
- Ningbo/Shanghai
- Picture Example:
![package-img]()
push button switch waterproof 3 pin push button switch
CMP 19mm stainless steel or copper platd chromium 3 pin push button switch,waterproof anti-vandal push button switch
1.Thread Diameter:19mm
2.Operation type:Momentary (also have latching type)
3.Housing material:Stainless steel (or other, contact me)
4.Terminal type:soldering pin,(or solder with wires,socket)
5.Head type:High head,Flat head, Domed head with LED or not
6,LED color:red,green,white,blue,yellow,orange
7.Contact configuration:1NO1NC or 2NO2NC (DPDT switch)
8,Switch rating: 5A/250V AC/DC
9, Mechanical life: 1000000 Cycles, Electrical Life: 50000 Cycles
10, Operating Temp:-20ºC~+55ºC
11,IP67IK10, high quality
12,have TUV,CE,ROSH, SGS
1NO1NC is 3 pin push button switch. 2NO2NC is 6 pin push button switch
push button switch waterproof
Our products have achieved TUV,CE and passed SGS test.
You can customize the laser marking and colorized switch.
illuminated switch 3 pin push button switch
3 pin push button switch
Supply all products with factory price. If you order our products for the first time, we would like to recommend that you take some samples for testing, so that you will be secure and will find how the quality of our goods is.
Installation diameter : There are10mm 12mm and 16mm 19mm 22mm 25mm 28mm 30mm 40mm series push button switch.
(1) Our factory is specialized in the production of button switch made of stainless steel ,chromium plated brass or plastic.
(2) And our products are exported to Europe, the USA, the Middle East, Asia, etc. Our products have passed TUV,CE. We also offer OEM and ODM services.
(3) You can customize the laser marking and colorized switch.
(4)Transport mode: DHL,UPS,EMS,Fedex,China post, by sea and so on.
(5)Payment: Paypal ,T/T, Western Union.
(6). Customer Service:
We strive to provide excellent customer service. All emails will be answered within 24 hours. If you have any questions, please feel free to contact me.
3 pin push button switch
Email:cmpswitch66 (at) aliyun.com
We strive to provide excellent customer service. Please feel free to contact me for more pictures or details.We will reply within 24 hours.
3 pin push button switch
