Water well drilling rig down the hole Rotary mud and air drilling
Product instruction
1.150M drilling depth water well drilling rig is lightweight, efficient, multi purpose drilling equipment, which can use air, foam or mud rotary for percussive drilling according to different textures.water well drilling rig down the hole Rotary air and mud drilling
2.It is widely used in industrial and agricultural water conservancy projects, such as drilling wells, testing wells or other exploration boreholes, in particular, in drilling hole for geothermal heating it can also meet the engineering basis for reinforcement,loose gravel drilling rock formation connected with a variety of engineering water well drilling rig down the hole Rotary air and mud drilling
Technology Parameter
| Total Weight | 2800 kg |
| Drilling diameter | 90---203mm |
| Dimension(L * W * H) | 4400*2100*2300mm |
| Drilling depth | 0-150m |
| Speed of Rotary | 0---90r/min |
| Torque of Rotary | 2000N.m |
| Once promotion distance | 2000(mm) |
| Working pressure | 1.2---2.46(Mpa) |
| Air consumption | 16---25m³/min |
| Hoist Power | 45Kw |
| Rotate speed of diesel engine | 2400r/min |
| For rock | 6----20f |
| Impact frequency | 0—900r/min |
| Note: The Company’s products continued to improve; various design and technical specifications may change at any time, without any additional notice or obligation. | |
Product Real Photos
