Features:
1. Light weight. The main engine is only weighted 0.135tons ;
2. Unique design and simple drilling structure;
3. Easy to transport and can learn how to handle the machine in short time;
4. Can drill through hard stratum, unless thick rock layer ;
5. Can drill deep. Equipped with raser, reduce the labor intensity ;
6. High efficiency, the drilling speed can reach 20meters depth per hour, in plain area ;
7. Assure easily operation and long life span to save more labors and money for you;
8.The packing of the machine is wood box, the CBM is about 2.0m³, the total weight (complete set) is about 850KG .
Disc drilling rig application:
This machine mainly used for geothermal drilling, farm irrigation , house yard, gardens and water well drilling, drilling diameter is 500-1500mm, and drilling depth is 50-300m. It also can be used in small building piling, like farmhouse or factory and so on, the drilling diameter can reach 500mm and depth can be more than 10m.
Disc drilling rig parameter:
| Item | SPJ-300 | SPJ-400 | SPJ-600 |
| Drilling diameter | 500-1500mm | 500-1800mm | 500-2500mm |
| Drilling depth | 300m | 400m | 600m |
| Maximum output torque | 18KN/m | 18KN/m | - |
| Active drill rod | 108mmX108mmX4000mm | 108mmX108mmX4000mm | 108mmX108mmX4000mm |
| The main hoist capacity | 30KN | 30KN | 35KN |
| Auxiliary hoist capacity | 20KN | 20KN | 15KN |
| Rotary table diameter | 500-1000mm | 500-1200mm | 605mm |
| The vertical height of tower | 8.6m | 8.6m | - |
| Weight | 6.5t | 6.5t | - |
| Dimension | 840X205X800cm | 840X205X800cm | - |
