Semi-Universal Blade
Semi-Universal (SU) blade
SU blade combines the excellent penetration of the S blade and the high production capacity of the U blade.
Designed for superior load retention and penetration in tightly packed materials.
L-shaped push arms bring the blade closer to the machine, providing excellent maneuverability, balance and blade penetration.
Blades feature a strong box section design, made from high tensile strength steel to stand up to the most severe applications.
Undercarriage
Undercarriage is provided by a world class supplier ensures high reliability and resistance to wear.
Carrier rollers track rollers and idle rollers areall maintenance free.
Planetary final drive design delivers increased torque ratio for higher transmission efficiency and lower maintenance cost.
Durable final drive bearings and multiple wet disc brakes provide reliability, reduce system heat and extend overall life.
Hydrostatic Drive System
Hydrostatic drive with electronic control technology
Hydrostatic system delivers higher efficiency and maximumoutput traction force of 280KN. for 816, 350KN for 822.
Maintenance costs are reduced by 60% when compared tocompetitors with torque converter and transmission design.
Counter-rotation and power turn feature delivers excellentmaneuverability on job sites
Comfortable Operation
Counter rotation-Tracks counter rotate to provide best in class maneuverability.
Powered turn-Machine maintains full power through turns to increase productivity.
Cruise control-Operators can retain previous speed settings which makes operation easily.
Multi-function joystick allows for counter-rotation, powered turn and cruise control.
Pilot joystick control provides comfortable precise blade operation.
Structures
Machine structures are analyzed using Finite Element Analysis (FEA) and On Machine Stress Analysis (OMSA) toidentify and protect high stress areas.
Advanced structure welding technique, relieving weldingstress.Modular Radiator
New advanced cooling system designed to meet -43°C to +50°C ambient temperatures capability.
Modular designed radiator, easy to maintain remove and repair.
Radiator grill provides better heat dissipation, easy access for maintenance.
Maintenance
Electronic Control Module (ECM) fault diagnosis system, automatic diagnosis of eight key parameters.
Monitoring system provides three levels of alarm, toindicate fault diagnosis.
Hydrostatic system has longer service interval (2000 hrs), reduces maintenance time by 50%.
Implement valve mounted outside of hydraulic tank provides easy access to check and service.
Easy to operate
-Multi-function electronically controlled walking handle for in-situ rotation, power orientation and cruise control.
-Hydraulic pilot control for easy operation.
-Precise control work.
-The electronically controlled engine with high torque reserve coefficient can realize real-time switching economic, standard and heavy load modes under any working condition through multi-state switch to meet different working conditions.
-Electronically controlled engine stepless shift knob for precise control of engine speed and low engine speed.
-Throttle stepping selection mode, which can reduce the speed of the vehicle while keeping the engine speed constant, and it is more convenient for the engine power to play.
-Steering mode for fast and slow steering to meet different operator needs.
