- Applicable Industries:
- Construction works
- Condition:
- New
- Type:
- Rotary/Core Drilling Rig
- Power Type:
- Diesel
- Place of Origin:
- Shandong, China
- Brand Name:
- HengWang
- Usage:
- Coal/Ore/Water Well
- Dimension(L*W*H):
- 2.7*0.9*1.5m
- Weight:
- 880KG
- Certification:
- ISO9001
- Warranty:
- 1 Year
- After-sales Service Provided:
- Video technical support, Free spare parts, Online support, Field installation, commissioning and training, Field maintenance and repair service
- Product name:
- HW230 Hydraulic Drilling Rig
- Application:
- Water well drilling
- Drilling depth:
- 230m
- End hole caliber:
- 75mm
- Maximum open hole caliber:
- 260mm
- Drill rod caliber:
- 50mm
- Spindle Speed(r/min):
- 142,285,570 r/min
- Spindle stroke:
- 450mm
- Tightrope caliber:
- 27m
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 2.8X1X1.6 cm
- Single gross weight:
- 950.0 kg
- Package Type:
- Wooden case
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Set) 1 - 1 >1 Est. Time(days) 5 To be negotiated
HW-Hydraulic DRILLING RIG!!!!
HWseries hydraulic drilling rig is a kid of widely used portable drill machine. It is uitbale for drilling water well, geological survey, geological core drilling, small grouting holes, blasting holes of railway, water conservanc, bridges, dam foundation and other buildings. According to different strata, it drills by choosing different bits, such as, diamond composite films and alloy.
Main features
1.It improves drilling efficiency and reduces labor intensity with hydraulic automatic feeding mechanism.
2.It can be achieved without stopping to change rods, easy to operate, safe and reliable with ball clip holding mechanism or hydraulic chuck.
3.It has hole bottom pressure gauge to be easy tp master the situation in the hole.
4.It also has advantage of compact structure, concentrated handle, small footprint, light weight, strong decomposition, easy to move.It can be operated in plains and mountain areas.
HW-160/190/230
.
HW-160T/190T/230T
1 set include all accessories will be used.
(Please contact us for list)
HW-160L/190L/230L
1 set include all accessories will be used.
(Please contact us for Details)
HW-160C/190C/230C
1 set include all accessories will be used.
(Please contact us for Details)
HW XY-3
Hydraulic Drilling rig
Max.drilling depth:600m
HW XY-44A
Hydraulic Drilling rig
Max.drilling depth:1400m
HW XY-8
Hydraulic Drilling rig
Max.drilling depth:3000m
HW-S30
Pneumatic Drilling rig
Max.drilling depth:50m
Including Air Compressor for choice
HQZ150/180/260/300/400/500
Pneumatic Drilling rig
Max.drilling depth:
150M/180M/26M0/300M/400M/500M
Including Air Compressor for choice
HWL-260L/300L/400L Water/air Drilling Rig
Hydraulic/Pneumatic Drilling rig
Max.drilling depth:260m/300m/400m
