- Place of Origin:
- Chongqing, China
- Brand Name:
- JUVI
- Model Number:
- capstan-006
- Power Source:
- Electric
- Application:
- Boat
- Product name:
- 3000W Stainless Steel Drum Winch Capstan Winch
- Max. Load (kg):
- 480
- Max. Pull (kg):
- 990
- Motor:
- 3KW
- Hz:
- 3PH/50HZ
- Power Supply:
- 380V
- Line Speed:
- 20m/min
- Weight:
- 74KG
- Material:
- Stainless Steel 316
- Rope size:
- 24-28mm
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 30X30X20 cm
- Single gross weight:
- 15.0 kg
- Package Type:
- Neutral packing
- Lead Time:
Quantity(Piece) 1 - 50 >50 Est. Time(days) 7 To be negotiated
3000W Stainless Steel Drum Winch Capstan Winch
Model | Net Weight (kg) | Power Supply | Motor | Max. Load (kg) | Max. Pull (kg) | Line Speed | Rope Size | Hz | Lift Working Load (kg) |
capstan-005 | 24 | 380V | 2200W | 710 | 710 | 25m/min | 20-25mm | 3PH/50HZ | 320 |
capstan-006 | 74 | 3000W | 990 | 990 | 20m/min | 24-28mm | 480 | ||
capstan-007 | 92 | 4000W | 1560 | 1560 | 26-30mm | 690 | |||
capstan-008 | 146 | 5500W | 2340 | 2340 | 28-34mm | 1010 |
Features:
1. Polished stainless steel finish.
2. Fluted capstan for line grip.
3. Reversible motor.
4. Easily disassembled for servicing: disassemble from top and bottom.
5. Large capstan drums for increased line hold.
6. Gearbox is driven by a vertically mounted below deck.
7. Fit include hand-switch, foot-switch,relay and solenoid.
1. Marine ship yacht boat light: Navigation signal light, Incandescent light, Fluorescent light, Searchlight, Explosion-proof light etc.
2. Marine deck: Winch, Windlass, Capstan (AC, DC, Vertical, Horizontal, Electric, Hydraulic etc.)
3. Marine deck mooring: Anchor, Anchor chain.
4. Marine life-saving: Rescue boat, Life Jacket, Buoy etc.
5. Customized products according to customers" request.
Q1: Why we choose you?
11 professional engineers can provide overall solution services.
13 years specialising in marine deck equipment .
18 long-term cooperation supporting factories.
24 hours a day after-sale technical support .
Q2: What kind of payments do you accept?
T/T, L/C, Western Union, D/A, D/P, MoneyGram, Paypal etc..
Q3: How about the Delivery Time?
We could finish the production within 30 days
Q4: What"s the MOQ?
MOQ is 1 set.
Address:3Rd Buliding, Xinke International Building,Yubei District, Chongqing, China
