300W Marine Explosion proof marine spot light
The scope of application
Applied to the explosive gas place zone 1 zone 2 with the temperature group T1-T4,also suitable for remote illumination
Products characteristic
Good quality aluminium shell ,brass net shield,toughened glass .The light body can rotate 350° horizontally and 45°up and down.
Adopt standard
Conform to National standard GB3836, GB12045 (THE TECHNICAL CONDITION OF MARINE EXPLOSION-PROOF LIGHT).
Production authentication
1. Passed the examination of National Explosion-proof Safety Supervisal and Inspection station for Luminaire.
1. Approval by CCS(China of National Classification Explosion-proof Society Safety ), certificate number 00515Q20619ROM.
Specifications
| Type | Explosion-proof Mark | Voltage | Power | Illuminant | Lamp Holder | Protection class | Cable outside diameter | Material | Weight |
| CFTl | Exd IIBT2 | 220V/50Hz 220V/60Hz | 400W | High-prassure mercury light | E40 | IP56 | φ12-φ14.5 | Aluminium | 10kg |
| 450W | Self-ballast mercur bulb | ||||||||
| 500w | Incandescent |
1. Marine ship yacht boat light: Navigation signal light, Incandescent light, Fluorescent light, Searchlight, Explosion-proof light etc.
2. Marine deck: Winch, Windlass, Capstan (AC, DC, Vertical, Horizontal, Electric, Hydraulic etc.)
3. Marine deck mooring: Anchor, Anchor chain.
4. Marine life-saving: Rescue boat, Life Jacket, Buoy etc.
5. Customized products according to customers" request.
