- Place of Origin:
- Chongqing, China
- Brand Name:
- JUVI
- Model Number:
- capstan-008
- Power Source:
- Electric
- Application:
- Boat yacht anchor winch
- Product name:
- 380Vmarine boat capstan winch
- Motor:
- 5500W
- Power Supply:
- 380V
- Max. Load (kg):
- 1010kg
- Max. Pull (kg):
- 2340kg
- Hz:
- 3PH/50HZ
- Weight:
- 146KG
- Line Speed:
- 20m/min
- Rope size:
- 28-34mm
- Material:
- Stainless Steel 316
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 110X28X28 cm
- Single gross weight:
- 150.0 kg
- Package Type:
- Neutral packing
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 50 >50 Est. Time(days) 7 To be negotiated
380V marine boat capstan winch
| Model | Net Weight (kg) | Power Supply | Motor | Max. Load (kg) | Max. Pull (kg) | Line Speed | Rope Size | Hz | Lift Working Load (kg) |
| capstan-005 | 24 | 380V | 2200W | 710 | 710 | 25m/min | 20-25mm | 3PH/50HZ | 320 |
| capstan-006 | 74 | 3000W | 990 | 990 | 20m/min | 24-28mm | 480 | ||
| capstan-007 | 92 | 4000W | 1560 | 1560 | 26-30mm | 690 | |||
| capstan-008 | 146 | 5500W | 2340 | 2340 | 28-34mm | 1010 |
Features:
1.Polished stainless steel finish.
2.Fluted capstan for line grip.
3.Motors work very well with good pull.
4.Mooring a vessel will be simple by using stern handing capstans.
5.A range of capstans and power size are available.
1. Marine ship yacht boat light: Navigation signal light, Incandescent light, Fluorescent light, Searchlight, Explosion-proof light etc.
2. Marine deck: Winch, Windlass, Capstan (AC, DC, Vertical, Horizontal, Electric, Hydraulic etc.)
3. Marine deck mooring: Anchor, Anchor chain.
4. Marine life-saving: Rescue boat, Life Jacket, Buoy etc.
5. Customized products according to customers" request.
