The scope of application
Applied to the explosive gas place zone 1 zone 2 with the temperature group T1-T4,also suitable for remote illumination.
Products characteristic
Good quality aluminium shell ,brass net shield,toughened glass .The light body can rotate 350° horizontally and 45°up and down.
Production authentication
1. Passed the examination of National Explosion-proof Safety Supervisal and Inspection station for Luminaire.
1. Approval by CCS(China of National Classification Explosion-proof Society Safety ), certificate number 00515Q20619ROM
Specifications
| Type | Explosion-proof Mark | Voltage | Power | Illuminant | Lamp Holder | Protection class | Cable outside diameter | Material | Weight |
| CFT1 | Exd IIBT2 | 100V/200V 220V | 300w | High-prassure mercury light | E40 | IP56 | φ12-φ14.5 | Aluminium | 10kg |
| 400W | High-prassure mercury light | ||||||||
| 450W | Self-ballast mercur bulb | ||||||||
| 500w | Incandescent |
1. Marine ship yacht boat light: Navigation signal light, Incandescent light, Fluorescent light, Searchlight, Explosion-proof light etc.
2. Marine deck: Winch, Windlass, Capstan (AC, DC, Vertical, Horizontal, Electric, Hydraulic etc.)
3. Marine deck mooring: Anchor, Anchor chain.
4. Marine life-saving: Rescue boat, Life Jacket, Buoy etc.
5. Customized products according to customers" request.
Q1: Why we choose you?
11 professional engineers can provide overall solution services.
13 years specialising in marine deck equipment .
18 long-term cooperation supporting factories.
24 hours a day after-sale technical support .
Q2: What kind of payments do you accept?
T/T, L/C, Western Union, D/A, D/P, MoneyGram, Paypal etc..
Q3: How about the Delivery Time?
We could finish the production within 30 days
Q4: What"s the MOQ?
MOQ is 1 set.
