manufacturer two capstan two drum gypsy horizontal anchor windlass JVH-016
Click on the image to view the original image
Product： views：2manufacturer two capstan two drum gypsy horizontal anchor windlass JVH-016
Branch： JUVI
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-11-19 19:00
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Chongqing, China
Brand Name:
JUVI
Model Number:
JVH-016
Power Source:
Electric
Application:
Boat
Capacity:
38kg
Product name:
horizontal windlass
Motor:
3000W
Lift Working Load:
1200kg
Power Supply:
220V/380V
Max. Lift Load:
2500kg
Chain Size:
10-13mm
Line Speed:
20m/min
Rope Size:
20-24mm
Material:
stainless steel
Weight:
38KG
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Neutral packing
Port
Shanghai/Guangzhou/Shenzhen
Lead Time:
Quantity(Pieces)1 - 1 >1
Est. Time(days)5To be negotiated
Product Description





Horizontal windlass



Net Weight (kg)

Power Supply

Motor

No Load Absorption

Max. Load (kg)

Max. Pull (kg)

Line Speed

Rope Size

Chain Size

SH400

13.5

12V/24V

600W



210

600

22m/min

6/7mm



SH1000

18

1000W



350

750

25m/min

8mm



JVH-011

16

12V/24V

600W

50A

190

600

30m/min

12-14mm

6-7mm

JVH-012

25.5

1000W

90A

350

750

25m/min

14-16mm

8-10mm

JVH-013

32

1400W

125A

520

1100

25m/min

18-20mm

JVH-014

34

1600W

140A

660

1400

20m/min

20-24mm

10-12mm

JVH-015

36

220V/380V

2000W

6A

900

2000

10-13mm

JVH-016

38

3000W

9A

1200

2500

10-13mm



1. twin capstan, single gypsy, but you also can choose twin gypsy.

2. Reversible motor.

3. Independent operation of capstans and gypsy by declutching the drive.

4. Simple deck mounted installation with no under deck parts.

5. Simplified maintenance with ability to strip the running gear (chain-wheel and drum) from the windlass without disturbing the windlass mounting.

6. Totally sealed gearbox with ground worm drive.

7. Horizontal windlass casing are cast marine grade aluminium alloy with white epoxy enamel finish.

8. Fit include hand-switch, control box and wrench.
