Home > Products > GB005H Boat Fast line speed high speed electric winch windlass Horizontal
GB005H Boat Fast line speed high speed electric winch windlass Horizontal
Click on the image to view the original image
Product： views：2GB005H Boat Fast line speed high speed electric winch windlass Horizontal
Branch： JUVI
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-11-19 19:00
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Chongqing, China
Brand Name:
JUVI
Model Number:
GB005H
Power Source:
Electric
Application:
Boat
Capacity:
2000kg
Product name:
Boat Fast line speed high speed electric windlass Horizontal
Motor:
6000W
Power Supply:
3PH/50HZ
Max. Load (kg):
900
Max. Pull (kg):
2000
Line Speed:
20m/min
Weight:
490kg
Material:
Aluminum
Chain size:
19mm
Usage:
Boat
Supply Ability
Supply Ability:
10000 Set/Sets per Month
Packaging & Delivery
Packaging Details
Standard Export Packaging
Port
Shanghai/Guangzhou/Shenzhen
Lead Time:
Quantity(Sets)1 - 20 >20
Est. Time(days)1To be negotiated
Product Description

GB005H Boat Fast line speed high speed electric winch windlass Horizontal

GB Series

Horizontal

Windlass

Model

Net

Weight

(kg)

Motor

Max.

Load
(kg)

Max.

Pull (kg)

Line SpeedChain SizePower supply
GB001H1602200W19060030m/min12.5mm3PH/50HZ
GB002H2603500W35075025m/min14mm
GB003H3204000W520110016mm
GB004H4105000W660140020m/min17.5mm
GB005H4906000W900200019mm
GB006H5307500W1200250020.5mm

Features:

1. Twin gypsy, twin brakes, one capstan, but you also choose twin capstans.

2. Independent operation of capstans and gypsy by declutching the drive.

3. Simple deck mounted installation with no under deck parts.

4. Simplified maintenance with ability to strip the running gear (chain-wheel and drum) from the windlass without disturbing the windlass mounting.

Other products

Company Information

1. Marine Lighting: Navigation signal light, Incandescent light, Fluorescent light, Searchlight, Explosion-proof light etc.
2. Marine Deck Equipments: Winch, Windlass, Capstan (AC, DC, Vertical, Horizontal, Electric, Hydraulic etc.)
3. Marine Deck Mooring: Anchor, Anchor Chain.
4. Marine Life-saving: Rescue boat, Life Jacket, Buoy etc.
5. Customized products according to customers" request.







Advantages





Customers Visiting





Packaging & Shipping

I. Packaging

1.Wooden Case; 2.Iron Frame; 3.According to customers" request;
II. Shipping
By Express/ Air/ Sea/ Train.



FAQ

Q1: Why we choose you?

  11 professional engineers can provide overall solution services.

  13 years specialising in marine deck equipment .

  18 long-term cooperation supporting factories.

  24 hours a day after-sale technical support .

Q2: What kind of payments do you accept?

 T/T, L/C, Western Union, D/A, D/P, MoneyGram, Paypal etc..

Q3: How about the Delivery Time?

  We could finish the production within 30 days

Q4: What"s the MOQ?

   MOQ is 1 set.
