| 1. Approval quality | 2. Easy to Operate | 3. Certification: Applicable | 4. Certification: ISO9001:2008 |
Features:
l Compact and small size, easy and direct operation, portable
l Accurate pulse pace identification function
l High accuracy digital filter, auto baseline adjustment
l Working modes: Manual, Automatic, Arrythmia Analysis, Storage
l 80mm, three channel format recording, excellent automatic interpretation
l 800x480 graphic 3.5 inch color LCD to simultaneously display detailed ECG information
l 250 cases storage. SD card storage is optional
l Adapt to 110-230V,50/60Hz power supply
l Built-in rechargeable Ni-MH battery continuously
l working for about 3 hours.
l USB, Rs232 port support USB disk storage, USB printing,
l Code scanning and PC ECG software. (Optional function )
Technical Specification:
Lead: Standard 12 leads
Lead acquisition: 12bit/1000Hz (synchronously 12 leads)
Work mode: Manual / Auto / R-R Analysis
Filter: . AC Filter : 50Hz / 60Hz
. EMG Filter : 25Hz / 45Hz
. Anti-Drift Filter : 0.15Hz ( Adaptive )
CMMR: ≥100dB ( with AC Filter )
Input circuit:Floating ; Protection circuit againt
Defibrillator effect
Input impedance:≥50MΩ
Input circuit current: ≤0.05μA
Patient current leakage:<10 μA
Calibrating voltage:1mV ±2%
Voltage tolerance:≥± 500mV
Time constant:≥3.2s
Frequency response:0.05 ~160Hz ( -3db )
Noise level:<15μVp-p
Inter-channel interference:≤0.5mm
Sensitivity :Auto, 2.5, 5, 10, 20, 40mm/mV (±3%)
Recording mode :.1ch, 3ch, 3ch+
.Default Man. Mode is 3ch format
.Default Auto. Mode is 3ch+ format
Paper speed:6.25, 12.5, 25, 50mm/s (± 3%)
Paper:80mm x 20m roll paper
Working environment:Temperature 5-40 C; Humidity 25-90%
Power supply:. AC 110-230V (±10%), 50/60Hz (±1Hz ), 40VA
. DC Built-in rechargeable batter,12V (1500mAh)
Dimension / Weight:260mm x 217mm x 58mm, 1.4kgs
Packing List:
Main unit 1set
Patient cable 1set
Limb electrodes 1set (4pcs)
Chest electrodes 1set (6pcs)
Power cable 1pc
Adaptor 1pc
Grounding cable 1pc
Fuse 2pcs
Paper axis 1pc
Printing paper 1roll
Operation manual 1copy
| |
