-Brief Introduction:
FTIR spectrometer consists of interferometer, sample chamber, detector, electrical system and data system.
-Main Specifications :
1. Wavelength range: 7800 cm-1 ~ 400 cm-1
2. Resolution: better than 1cm-1
3. Wavenumber precision: ±0.01cm-1
4. Transmittance repeatability: 0.5%T
5. 100%T line SNR: better than 15,000:1 (RMS value, at 2100cm-1, 4 cm-1resolution, DTGS detector, 1 minute data collecting)
6. 100% line T inclining:
Wavelength (cm-1) 100%T line (%T)
500 ~ 800 98.0 ~ 102.0
1900 ~ 2200 99.5 ~ 100.5
2800 ~ 3200 99.5 ~ 100.5
4000 ~ 4400 98.5 ~ 101.5
7. Scan speed: 0.4 cm/s ~ 2.5 cm/s, selectable;
8. Detector: DTGS;
9. Data system: basic configuration is all-purpose computer;
Memory: ≥64MB
CD-ROM drive
Hard disk: ≥10GB
USB interface
Display: high-resolution color display;
10. Output device: ink printer or laser printer.
-Standard Configuration :
- 1. High performance IR source with air-cooled high-efficiency reflex sphere;
- 2. Cube-corner Michelson interferometer system;
- 3. Electrical system;
- 4. External optical path sampling system;
- 5. DTGS infrared detector system;
- 6. All-purpose computer data system.
-Optional Accessories:
- 1. Laser printer;
- 2. Hydraulic press;
- 3. Agate mortar;
- 4. Dehumidifier;
- 5. Diffuse/Specular Reflectance;
- 6. Horizontal ATR ;
- 7. Variable Angle ATR ;
- 8. Infrared microscope;
- 9. GC-IR interface;
- 10. Photoacoustic Accessory;
- 11. Various Gas Cells and Various Liquid Cells
Technical Parameters:
| FTIR Spectrometer | |
| Model No.: | WQF-510A |
| Spectral range: | 7800~400cm-1 |
| Resolution: | Better than 0.85cm-1 |
| Wavenumber Precision | ±0.01cm-1 |
| Scanning Speed | 5-step adjustable for different applications |
| Signal to noise ratio | better than 15,000:1 (RMS value, at 2100cm-1,resolution: 4cm-1, detector: DTGS, 1 minute data collection) |
| Beam splitter | Ge coated KBr |
| Infrared Source | Air-cooled, high efficiency Reflex Sphere module |
| Detector | DTGS |
| Data system | Compatible computer |
| Software | FT-IR software contains all routines needed for basic spectrometer operations, including library search, quantitation and spectrum export |
| IR Library | 11 IR libraries included |
Usual package,paper box with foam to keep fixed.
If you have other requirement , we can do as you want,such as wooden box .
Below pictures are just sample as reference.
