Home > Products > 253.7nm uvc germicidal lamp 320w uv lamp replace 55w for air purifier uv sterilization vocs treatment
253.7nm uvc germicidal lamp 320w uv lamp replace 55w for air purifier uv sterilization vocs treatment
Click on the image to view the original image
Product: views:4253.7nm uvc germicidal lamp 320w uv lamp replace 55w for air purifier uv sterilization vocs treatment
Branch: XPES
Unit Price: Negotiated
Min.Order:
Supply:
Delivery: Shipment within days since the date of payment
Valid until: Long Term
Updated on: 2019-12-03 17:37
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
XPES
Rated Power:
300W
Voltage:
100V-300V
Item Name:
UV lamp
UV type:
UVC
applications:
Water, air and surface sterilization
base material:
aluminum
tube material:
high purity quartz glass
Spectral Range:
200nm ~ 400nm
Rendering Index:
92.7
long life:
100,000 hours
Color Temperature:
30000K
Power Factor:
0.998
Supply Ability
Supply Ability:
8000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Standard export cartonswith polyfoam inside
Port
Shenzhen/Guangzhou/Foshan

Description:

XPES induction UV lamp tube use a special glass that transmits ultra-violet light in a spectral band that can be effective for sterilisation. A proven technology for the destructionof air-borne bacteria, viruses and mold spores.Improved system efficiency. The UVC wavelength of 254 nm will inactivate bacteria, viruses, mold, and cysts by preventing pecification.



Technical parameter:

ModelPower  VoltageCurrent  Start Time   Power Factor   Lumens  CRI   Size
XP-SJ-LAMP300W100-300V  1.36A<0.5Sec≥0.9924000lm≥80  388*340*90mm



Advantages of XPES UV lamp tube:

1. Using quality high purity quartz glass

2. Hot cathode,pre-heat start

3. Super long life: 100,000 hrs

4. Generally used in the sterilization and purifying of Aquarium

Product Display:



Testing:

Watt/W

testing period/
min

Test time / sec

Ozone concentration-/ppm


ozne generation


ozone generation peak value( g/KW.h)

281.5

10

600

0.27

0.0055

0.006



20

1200

0.47

0.0048





30

1800

0.65

0.0044



40

2400

0.78

0.0040



50

3000

0.83

0.0034



60

3600

0.92

0.0031



70

4200

0.93

0.0027



80

4800

0.95

0.0024



90

5400

1.01

0.0023



100

6000

1.02

0.0021



110

6600

1.05

0.0020



120

7200

1.06

0.0018





Ultraviolet Sterilization is unmatched in its efficiency, simplicity, and dependability when applied as a microorganism disinfectant. UV sterilization is a proven solution to waterborne planktonic algae as well as other harmful pathogen problems.



Warning:
Don’t look at the UV lamp directly when the UV lamp is igniting. Don’t irradiate the skin with UV-lamp. Hold a piece of ordinary glass before your eyes when you need to look at the UV-lamp. Please keep the surface of the tube clean to prevent the dust or the dirt from affecting the ultraviolet ray’s output. Please don’t touch the quartz glass with bare hands while installing the lamp and using it. The quartz glass can be cleaned by using alcohol tampon.



Applications:

Water, air and surface sterilization.

Also the germicidal lamp is commonly used in school, hotel, home, office and other environments for air and surface sterilization.Contact US Now:
