Body in die-cast copper-free aluminum alloy, treated by electrostatic spraying, with good performance of high temperature resistance and climate resistance.Temperedglass with good transmittancy.
Overview
Quick Details
- Input Voltage(V):
- AC90-265V
- Lamp Power(W):
- 50
- CRI (Ra>):
- 0.96
- Lamp Luminous Flux(lm):
- 5500
- IP Rating:
- IP65
- Working Lifetime(Hour):
- 50000
- Working Temperature(℃):
- -30 - 45
- Certification:
- BV, CCC, CE, CQC, C-tick, FCC, RoHS
- Place of Origin:
- Sichuan, China
- Brand Name:
- HKV
- Light Source:
- LED
- Product Name:
- Explosion Proof Light
- Application:
- Gas Industry
- Warranty:
- 3-5Years
- Material:
- Aluminum Alloy
- Power:
- 50/60W
- Size (mm):
- 225x225x267
- Weight:
- 3.62kg
- EX Code:
- Exd IIC T6
- LED Light Source:
- Top Brand SMD
- Lamp Luminous Efficiency(lm/w):
- 110-130
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 50X29X18 cm
- Single gross weight:
- 4.0 kg
- Package Type:
- carton 50W 60W Explosion Proof Light Led Gas Station Light Led Explosion Proof Lighting
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 10 11 - 50 51 - 100 >100 Est. Time(days) 5 7 14 To be negotiated
Setting Information
50W 60W Explosion Proof Light Led Gas Station Light Led Explosion Proof Lighting
Model | HKV-FB50 | HKV-FB60 | HKV-FB80 | HKV-FB100 | HKV-FB150 | HKV-FB200 | |||||
Power | 50W | 60W | 80W | 100W | 150W | 200W | |||||
PF | 0.95 | 0.95 | 0.95 | 0.95 | 0.95 | 0.95 | |||||
Voltage | AC85-265V | AC85-265V | AC85-265V | AC85-265V | AC85-265V | AC85-265V | |||||
LM | 5500lm | 6600lm | 8800lm | 11000lm | 15000lm | 18000lm | |||||
LM/W | 110 lm/W | 110 lm/W | 110 lm/W | 110 lm/W | 110 lm/W | 110 lm/W | |||||
Working voltage | DC30-42V | DC30-42V | DC30-42V | DC30-42V | DC30-42V | DC30-42V | |||||
Ra | 0.95 | 0.95 | 0.95 | 0.95 | 0.95 | 0.95 | |||||
Working Temp | -30° ~+45° | -30° ~+45° | -30° ~+45° | -30° ~+45° | -30° ~+45° | -30° ~+45° | |||||
IP | IP 65 | IP 65 | IP 65 | IP 65 | IP 65 | IP 65 | |||||
Explosion Grape | Ex d e mb IIC T5 Gb | ||||||||||
Body | Dia-cast Al+ Anti-corrosion Painting | ||||||||||
Lens | 10mm toughened Glass | ||||||||||
Installation | Ceiling,frame,hanging tube, wall-mounted | ||||||||||
LED life-span | 30000hours | 30000 hours | 30000hours | 30000hours | 30000 hours | 30000 hours | |||||
N.W: | 3.5KG | 3.5KG | 7.5KG | 7.5KG | 14KG | 14KG | |||||
Corrosion Grape | WF2 | WF2 | WF2 | WF2 | WF2 | WF2 | |||||
Product Description
Overview
Features
Body
Driver
IsolationClass l, Protection OPP/OVP/SCP/OTP, Wide input voltage 90-265Vac , built-in active PFC> 0.96 , THD<15% , Surge Protection 10KV/6KV/4KV
Sources
LEDlight source with different possibilities of temperature color (standard Natural White 4000K,executions on request also with 3000K, 6000K). High coefficient of performance chromaticCRI> 85. lifespan> 50,000hrs.
Aplication
ldeal to be used in the oilfield, chemical industry, steel industry, power, port, Petroleum etc. Harsh environment, moist area. Zone 1, Zone2
Gas explosive environment: Group IIA llB IICTemperature class: T5 to T6
Dimension(mm)& Installation:
