100W Intelligent Infrared Induction Light Flood Light 100W Led Intelligent Induction Flood Light
Click on the image to view the original image
Product： views：3100W Intelligent Infrared Induction Light Flood Light 100W Led Intelligent Induction Flood Light
Branch： HKV
Size： 42.5X17.8X35.3 cm
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-11-19 20:34
  Negotiated
Product Details
Overview
Quick Details
Input Voltage(V):
AC 220V
CRI (Ra>):
80
Beam Angle(°):
25°, 60°, large angle
Working Lifetime(Hour):
50000
Lamp Body Material:
Aluminum Alloy
IP Rating:
IP65
Certification:
CE, RoHS
Place of Origin:
Sichuan, China
Brand Name:
HKV
Model Number:
HKV-FM350
Application:
WAREHOUSE
Light Source:
LED
Lamp Luminous Flux(lm):
160LM/WMAX
Working Temperature(℃):
-35℃~+60℃
Input Voltage:
AC 220V
Frequency Range:
50Hz ~ 60Hz
Power Efficiency:
95% MAX
Power Factor:
> 0.95
Led Luminous Efficiency:
160LM/WMAX
Light source:
Flip chip 3030
Beam angle:
25°, 60°, large angle
Connect wire:
Blue:NYellow/Green:G Brown: L
IP Grade:
IP65
Warranty:
3 Years/50000 Hours

Packaging & Delivery

Selling Units:
Single item
Single package size:
42.5X17.8X35.3 cm
Single gross weight:
8.0 kg
Package Type:
1 Pcs/Carton 100W Intelligent Infrared Induction Light Flood Light 100W Led Intelligent Induction Flood Light
Lead Time:
Quantity(Piece)1 - 1011 - 5051 - 100>100
Est. Time(days)71425To be negotiated
Product Description

100W Intelligent Infrared Induction Light Flood Light 100W Led Intelligent Induction Flood Light
Main Technical Parameters
 Input Voltage
AC 220V
Frequency Range
50Hz ～ 60Hz
Power Efficiency
95% MAX
Power Factor
﹥0.95
Led Luminous Efficiency
160LM/WMAX
Color Rendering Index
70-90
Light source
Flip chip COB/3030
Beam angle
25°, 60°, large angle
Ambient temperature
-35℃～+60℃
Storage temperature
-20℃～+40℃
Connect wire
Blue： N                              Yellow/Green：G                               Brown： L
IP Grade
IP65
Certification
CE、ROHS
Power / Light Source Brand
Multi-brand choice
Intelligent Induction FloodLight
LED intelligent induction flood light is in the traditional separation of the corridor body sensor lamp developedon the basis of a combination ofsensor sensor and LED flood light combination. With super energy saving , intelligent control , light source and control module integration and other characteristics, can replace the traditional corridor body sensor lights , Corridor sound and light control lights and touch switch lights.
Photometric Division
Light Distribution Curve
Average Illuminance Map
Dimensions
Decomposition structure
Structural Materials

1. Reflector
Uniform spot, light reflectance >96%

2. Led High quality light source,
high light efficiency, low light decay

3. Drive power
Adopt the current mainstream power supply
of the market, quality assurance

4. Tempered glassPreferred material, high light transmittance

5. Tempered glass
Preferred material, high light transmittance

6. Screw
High quality 304 stainless steel

7. Heat sink
Beautiful appearance and good heat dissipation

8. Waterproof stripHigh quality silicone, long-term use without deterioration



Lamp installation instructions








Fix the fixture in the mounting position








Adjust the luminaire to the actual required illumination angle



Access to the city power:

InputBrown wire connected to the fire line;Blue line is connected to the zero line;Yellow/green wire grounding wire.
