Click on the image to view the original image
Body
Body in die cast copper-free aluminum alloy, treated by electrostatic spraying, with good performance of high temperature resistance and climate resistance. Tempered glass with good transmittancy.
Overview
Quick Details
- Input Voltage(V):
- AC85-265V
- Lamp Power(W):
- 60
- CRI (Ra>):
- 80
- Lamp Luminous Flux(lm):
- 5400
- IP Rating:
- IP66
- Working Lifetime(Hour):
- 50000
- Working Temperature(℃):
- -30 - 45
- Certification:
- CE, RoHS, EX/IECEX/CE
- Place of Origin:
- Sichuan, China
- Brand Name:
- HKV
- Light Source:
- LED
- Power:
- 60 W
- Power Factor:
- PF>0.95
- LM/W:
- 90 lm/W
- LED Voltage:
- DC30-42V
- Color Temp.:
- 2700-6500K
- Body:
- Dia-cast Al+Anti-corrosion Painting
- Lens:
- 10mm toughened Glass
- Corrosion Grape:
- WF2
- LM:
- 4500-5400LM
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 52X26X27 cm
- Single gross weight:
- 20.0 kg
- Package Type:
- Inner carton size: 25*25*25 cm Outer carton size: 52*26*27(2pcs/ctn) N.W :9kg G.W : 20kg/ctn Industrial Led 60W Chemical Hazardous Area Light Gas Station Light Explosion Proof Led Flood Light
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 10 11 - 50 51 - 100 >100 Est. Time(days) 7 15 30 To be negotiated
Product Parameters
Industrial Led 60W Chemical Hazardous Area Light Gas Station Light Explosion Proof Led Flood Light
Power | 30W | 50W | 60W | 80W | 100W | ||||
Voltage | AC85-265V | AC85-265V | AC85-265V | AC85-265V | AC85-265V | ||||
Power Factor | 0.95 | 0.95 | 0.95 | 0.95 | 0.95 | ||||
LM | 2700lm | 4500lm | 5400lm | 7200lm | 9000lm | ||||
LM/W | 90 lm/W | 90 lm/W | 90 lm/W | 90 lm/W | 90 lm/W | ||||
Color Temp | 2700-6500k | 2700-6500k | 2700-6500k | 2700-6500k | 2700-6500k | ||||
Ra | 80 | 80 | 80 | 80 | 80 | ||||
Working Temp | -30°C ~+45°C | -30°C ~+45°C | -30°C ~+45°C | -30°C ~+45°C | -30°C ~+45°C | ||||
IP | IP66 | IP66 | IP66 | IP66 | IP66 | ||||
Body | Dia-cast Al+Anti-corrosion Painting | ||||||||
Lens | 10mm toughened Glass | ||||||||
Corrosion Grape | WF2 | WF2 | WF2 | WF2 | WF2 | ||||
LED life-span | 50,000 hours | 50,000 hours | 50,000 hours | 50,000 hours | 50,000 hours | ||||
N.Weight | 1.64KG | 4.05KG | 4.05KG | 6.18KG | 6.18KG | ||||
Detailed Images
Industrial Led 60W Chemical Hazardous Area Light Gas Station Light Explosion Proof Led Flood Light
Sources
LED light source with different possibilities of temperature color (standard Natural White 4000K executions on request also with 3000K 6000K).High coefficientofperformance chromatic CRI> 85 lifespan> 50,000hrs.
Driver
Isolation Class l, Protection: OPP/OVP/SCP/OTP.Wide input voltage 90 265Vac, built-in active PFC> 0.96, THD < 15%, Surge Protection 10KV/6KV/4KV
Appliation
ldeal to be used in the oilfield,chemical industry, steel industry,power port.Petroleum etc.
Harsh environmentmoist area.
Zone1, Zone2
Gas explosive environment: Group IA IB IIC
Temperature dlass: T5 to T6
MORE DETIALS , PLEASE SEND INQUIRY TO US.
