Body
Body in die cast copper-free aluminum alloy, treated by electrostatic spraying, with good performance of high temperature resistance and climate resistance. Tempered glass with good transmittancy.
Overview
Quick Details
- Input Voltage(V):
- AC85-265V
- Lamp Power(W):
- 30
- CRI (Ra>):
- 80
- Lamp Luminous Flux(lm):
- 2700
- IP Rating:
- IP66
- Working Lifetime(Hour):
- 50000
- Working Temperature(℃):
- -30 - 45
- Certification:
- CE, RoHS, EX/IECEX/CE
- Place of Origin:
- Sichuan, China
- Brand Name:
- HKV
- Light Source:
- LED
- Power:
- 30W
- Power Factor:
- PF>0.95
- LM/W:
- 90 lm/W
- LED Voltage:
- DC30-42V
- Color Temp.:
- 2700-6500K
- Body:
- Dia-cast Al+Anti-corrosion Painting
- Lens:
- 10mm toughened Glass
- Corrosion Grape:
- WF2
- LM:
- 2700LM
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 40X40X21 cm
- Single gross weight:
- 2.9 kg
- Package Type:
- N.W.: 2.9kg Inner carton size: 19*19*19cm Outer carton size: 40*40*21 (4pcs/ctn) G.W: 13kg/ctn Explosion Proof Lamp Led Gas Station Light 30W Flood Light Led Explosion Proof Lighting
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 10 11 - 50 51 - 100 >100 Est. Time(days) 7 14 25 To be negotiated
Product Parameters
Explosion Proof Lamp Led Gas Station Light 30W Flood Light Led Explosion Proof Lighting
Power | 30W | 50W | 60W | 80W | 100W | ||||
Voltage | AC85-265V | AC85-265V | AC85-265V | AC85-265V | AC85-265V | ||||
Power Factor | 0.95 | 0.95 | 0.95 | 0.95 | 0.95 | ||||
LM | 2700lm | 4500lm | 5400lm | 7200lm | 9000lm | ||||
LM/W | 90 lm/W | 90 lm/W | 90 lm/W | 90 lm/W | 90 lm/W | ||||
Color Temp | 2700-6500k | 2700-6500k | 2700-6500k | 2700-6500k | 2700-6500k | ||||
Ra | 80 | 80 | 80 | 80 | 80 | ||||
Working Temp | -30°C ~+45°C | -30°C ~+45°C | -30°C ~+45°C | -30°C ~+45°C | -30°C ~+45°C | ||||
IP | IP66 | IP66 | IP66 | IP66 | IP66 | ||||
Body | Dia-cast Al+Anti-corrosion Painting | ||||||||
Lens | 10mm toughened Glass | ||||||||
Corrosion Grape | WF2 | WF2 | WF2 | WF2 | WF2 | ||||
LED life-span | 50,000 hours | 50,000 hours | 50,000 hours | 50,000 hours | 50,000 hours | ||||
N.Weight | 1.64KG | 4.05KG | 4.05KG | 6.18KG | 6.18KG | ||||
Detailed Images
Driver
Isolation Class l, Protection: OPP/OVP/SCP/OTP.Wide input voltage 90 265Vac, built-in active PFC> 0.96, THD < 15%, Surge Protection 10KV/6KV/4KV
Sources
LED light source with different possibilities of temperature color (standard Natural White 4000K executions on request also with 3000K 6000K).High coefficientofperformance chromatic CRI> 85 lifespan> 50,000hrs.
Appliation
ldeal to be used in the oilfield,chemical industry, steel industry,power port.Petroleum etc.
Harsh environmentmoist area.
Zone1, Zone2
Gas explosive environment: Group IA IB IIC
Temperature dlass: T5 to T6
MORE DETIALS , PLEASE SEND INQUIRY TO US.
FAQ
Q1. Why choose us?
A1:We are a professional LED Manufacturer and good at manufacturing LED flood light, LED high bay light, LED street lightand, LED mart light, LED explosion proof light and so on.As for LED,we have some advantages as below:Factory direct selling,Original designs,High quality control, fast delivery and competitive price.
Q2. Do you offer samples?
A2: Yes,samples are available. Please kindly let us know your requirement.
Q3. How to order?
A3:Submit an inquiry straightly , We will reply you at the earliest time we can.
Q4.How long does the package take to delivery to my address?
A4:For sample order, package arrives you in 10 Working days (3 days for production, another 1-5 working days for delivery); For bulk order, 30 days for North American Area(Shipping by Air).
Q5. Can you offer OEM service?
A5:Yes,we can offer OEM service, we have our own designer and skilled technicials at your service.
Q6: Do you offer guarantee for the products?
A6: Yes, we offer 2-5 years warranty to our products.
Q7: How to deal with the faulty?
A7: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%. Secondly, during the guarantee period, we will send new lights with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution including
re-call according to real situation.
