TFE 9210 Ip66 Soft White LED Light With no glare Easy to maintain and replace

Click on the image to view the original image

Product：	views：7TFE 9210 Ip66 Soft White LED Light With no glare Easy to maintain and replace
Branch：	GT
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-16 20:13

Product Details

Overview

Quick Details

Input Voltage(V):: AC100-260V

Lamp Power(W):: 100

CRI (Ra>):: 80

Lamp Luminous Flux(lm):: 7700

IP Rating:: IP66

Working Lifetime(Hour):: 100000

Working Temperature(℃):: -40 - 60

Certification:: BV, CCC, CE, FCC, RoHS

Place of Origin:: Zhejiang, China

Brand Name:: GT

Light Source:: LED

Input Power:: AC100-260V 50-60Hz

Luminous Flux:: 7700 Lm

Light Source Life:: 100000 h

Lamp Size:: 300*240*170mm

Lamp Weight:: 5.8 Kgs

Color Temperature:: 5700 K

Anti-corrosion grade:: WF2

Ex-mark:: Exd IIC T6

Insulation grade:: I

Lamp Luminous Efficiency:: >88%

Product Certification Verified

CE Certified.: Valid from 2018-03-06 until 2023-03-05

RoHS Certified.: Valid from 2018-02-02 until 2049-12-31

Supply Ability

Supply Ability:: 1000 Piece/Pieces per Month

Packaging & Delivery

Packaging Details: Carton

Port: Shanghai/Ningbo

Lead Time:

Quantity(Pieces)	1 - 50	51 - 100	101 - 500	>500
Est. Time(days)	10	15	30	To be negotiated

Product Description

Technical Parameters:

Item	Parameters
Light Source	100 W
Input Power	AC100-260V 50-60Hz
Luminous Flux	7700 Lm
Light Source Life	100000 h
Power Factor	>98 %
Luminaire Efficiency	>88 %
Lamp Size	300×240*170 mm
Lamp Weight	5.8 Kgs
Color Temperature	5700 K
Space-depth ratio	1.4 S/h
Inlet thread	3/4 G
Lead-in cable	Φ6-8 mm
Anti-corrosion grade	WF2
Insulation grade	Ⅰ
Protection grade	IP66
Ex-mark	Exd IIC T6

FEATURES

1.CE, ROHS, FCC, ATEX certified.

2.LED light source, power consumption is 20% of Incandescent light.

3.Soft white LED light with no glare, perfect electromagnetic compatibility.

4.Modular design, easy to maintain and replace.

5.Casing adopt AL die-casting molding & electrostatic spraying surface.

6.Different installation methods to meet different need.
