Home > Products > Black Plastic Double Pole Double Throw Mini T85 Rocker Switch
Black Plastic Double Pole Double Throw Mini T85 Rocker Switch
Click on the image to view the original image
Product: views:2Black Plastic Double Pole Double Throw Mini T85 Rocker Switch
Branch: Daier
Unit Price: Negotiated
Min.Order:
Supply:
Delivery: Shipment within days since the date of payment
Valid until: Long Term
Updated on: 2019-11-19 20:10
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
Daier
Model Number:
KCD1-1-202
Max. Current:
10A
Max. Voltage:
250VAC
Mechanical Life:
10000 Cycles
Item:
Rocker Switch
Model:
KCD1-1-202
Fuction:
ON-ON
Rating:
10A 125VAC; 6A 250VAC
Housing Color:
Black
Button Color:
Black, Red
Terminal type:
Solder Terminals
Operating Temperature:
-25℃~+85℃
Certificate:
CE,CQC
Standard:
IEC Standard

Packaging & Delivery

Selling Units:
Multiple of
Package size per batch:
15X15X7 cm
Gross weight per batch:
0.375 kg
Package Type:
100pcs/box,3000pcs/carton of Black Plastic Double Pole Double Throw Mini T85 Rocker Switch
Picture Example:
package-img
Lead Time:
Quantity(Piece)1 - 100000>100000
Est. Time(days)7To be negotiated
Product Description
lItem
Black Plastic Double Pole Double Throw Mini T85 Rocker Switch
Switch Function
ON ON   mini t85 rocker switch
Rating
10A 125VAC; 6A 250VAC
Contact Resistance
< 35MΩ
Insulation Resistance
500VDC 1000MΩMinute
Dielectric Strength
1500VAC, 1 Minute
Operating Temperature
-25°C~+85°C
Electrical life
10000 CYCLES

KCD1-1-202 6 Pin Rocker Switch:

Daier KCD1-1-202 on on of miniature rocker switch offer a high switching current in a compact design.

It is a snap-in mounted rocker switch with a high mechanical life in a rugged nylon 66 housing.

They have high quality for long life at heavy loads and industry-standard mounting dimensions.

This rocker switches can be used in a variety of applications, like water dispenser and extension socket and so on.
