- Place of Origin:
- Guangdong, China
- Brand Name:
- DF
- Bulb Type:
- LED
- Battery Type:
- Li-ion Lithium-ion
- Material:
- Cold Rolled Steel Sheet
- Usage:
- comercial lighting
- Certification:
- ETL
- Specifications:
- ETL518t-72-10w-180
- Battery:
- LIR 7.4V 5200mAh
- Input Voltage:
- AC100-277V
- Charge time:
- 24 Hours
- Warranty:
- 5-30W
- output Voltage:
- dc36v
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 47X33X11 cm
- Gross weight per batch:
- 9.5 kg
- Package Type:
- 8PCS/BOX
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 100 101 - 500 501 - 1000 >1000 Est. Time(days) 2 4 7 To be negotiated
ETL emergency power and emergency EIXT lighting 5w-30w180mins
1 .This product should be installed by trained electricians. Forbid connecting wires when power is on, make power on after make sure that there is no phenomenon of short circuit and the correction is ok.
2. Main power line: Live wire TL and null line N, connect to main power line directly. no switch can be allowed when emergency lighting. the law forbids the switch control emergency circuit.
3 .The wall switch only controls the main power, no function on emergency lighting. The Switch live wire SL and charging live wire TL should be in the same phase.
4. Green light-main power ,Red light-charging , Yellow light-mulfunction;Test: test button
5.Emergency lighting condition,three-color light is all out;
6. Digital circuits, self-test function (monthly inspection, annual inspection), fault or automatic alarm function cause by illegal operation.
7 .You should connect the led lamp and charge the emergency pack before use. In order to avoid emergency lighting function failure.
8 .The environment temperature of Emergency pack ranges from minus ten degrees centigrade to 50 degrees centigrade. High-temperature aging test is forbidded.
9 .Frequently test is prohibited . Each test interval is not less than one minute.
10 .Emergency movement is the core device which controls the battery charge or discharge and start the lighting when under emergency must ensure the wiring is correct. After under normal use, need to discharge once every three months for battery conservation and extend the battery life. Emergency lighting power installed and put into use, need to regularly check, maintain, examine and repair when discover the abnormal condition, or inform the supplier to deal with.
11 .Any problem, contact the manufacturer or supplier pls.
