- Place of Origin:
- Guangdong, China
- Brand Name:
- DF
- Bulb Type:
- LED
- Battery Type:
- NI MH BATTERY
- Material:
- Cold Rolled Steel Sheet
- Usage:
- emergency lighting
- Certification:
- FCC CE TUV ROHS UN38.83 MSDS
- Specifications:
- 168H18W90
- Product Name:
- Fire Emergency Lights
- Input Voltage:
- AC 85-265V
- Battery:
- nimh battery
- Charge time:
- 24 Hours
- Warranty:
- 10-25W
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 39X31X13 cm
- Gross weight per batch:
- 9.5 kg
- Package Type:
- 20PCS/BOX
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 10 11 - 100 101 - 1000 >1000 Est. Time(days) 1 2 7 To be negotiated
168H led emergency driver 20w90MIN ni-mh battery with CE FCC ROHS SAA
DF168H multi-function emergency power supply (< 25W LED light source, all models LED lamps or integrated LED lamps)
Applicable to all LED fluorescent lamps, LED lamp and other emergency lighting under 25W;
In combination with high temperature ni-mh, Ni - Cd, lithium battery LIR and other charging battery pack;
International circuit, 100% full power emergency, thin film PC board three-color indicator light detection switch;
note:
1 .This product should be installed by trained electricians. Forbid connecting wires when power is on, make power on after make sure that there is no phenomenon of short circuit and the correction is ok.
2. Main power line: Live wire TL and null line N, connect to main power line directly. no switch can be allowed when emergency lighting. the law forbids the switch control emergency circuit.
3 .The wall switch only controls the main power, no function on emergency lighting. The Switch live wire SL and charging live wire TL should be in the same phase.
4. Green light-main power ,Red light-charging , Yellow light-mulfunction;Test: test button
5.Emergency lighting condition,three-color light is all out;
6. Digital circuits, self-test function (monthly inspection, annual inspection), fault or automatic alarm function cause by illegal operation.
7 .You should connect the led lamp and charge the emergency pack before use. In order to avoid emergency lighting function failure.
8 .The environment temperature of Emergency pack ranges from minus ten degrees centigrade to 50 degrees centigrade. High-temperature aging test is forbidded.
9 .Frequently test is prohibited . Each test interval is not less than one minute.
10 .Emergency movement is the core device which controls the battery charge or discharge and start the lighting when under emergency must ensure the wiring is correct. After under normal use, need to discharge once every three months for battery conservation and extend the battery life. Emergency lighting power installed and put into use, need to regularly check, maintain, examine and repair when discover the abnormal condition, or inform the supplier to deal with.
11 .Any problem, contact the manufacturer or supplier pls.
