Click on the image to view the original image
- Place of Origin:
- Guangdong, China
- Brand Name:
- DF
- Bulb Type:
- LED
- Battery Type:
- lithium battery
- Material:
- Cold Rolled Steel Sheet
- Usage:
- emergency lighting system
- Certification:
- ETL/UL/CE/FCC/SAA/ROHS
- Specifications:
- ETL-518T-36-5W180
- Battery:
- Lithium Battery
- Input Voltage:
- AC 100~277V
- output voltage:
- dc36v
- Charge time:
- 24 Hours
- Lighting Time:
- 180mins
- Warranty:
- 3 Years
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 47X33X13 cm
- Gross weight per batch:
- 9.0 kg
- Package Type:
- 10PKS/outer box
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 10 11 - 100 101 - 1000 >1000 Est. Time(days) 1 2 10 To be negotiated
USA LED emergency power kit 5w-30w180mins ETL certificate emergency battery emergency light conversion kit
Emergency lighting parameters
Emergency power: 5±1W
Charging time: ≥12hours
Duration time: ≥180min
Conversion efficiency ≥80%
Power factor ≥90%
Emergency switching time: ≤ 1S
Lighting system continuous
The service life 20000 hours
Temperature range -10- 50℃
Humidity range 65%±20%
3.The installation and operation instruction
1—— Connect Live Wire TL+ LED external driver live wire input. This line can set a wall switch S. Swith line and Live wire must Keep with the phase.The wall switch only controls the main power, no function on emergency lighting.
2—— Connect the null line N+LED external driver nulll line input
3——Connect the earth wire
4—— Connect LED driver’s output positive
5—— Connect light source’s negative +light source external driver’s output negative
6—— Light positive
4.Notes:
1 .This product should be installed by trained electricians. Forbid connecting wires when power is on, make power on after make sure that there is no phenomenon of short circuit and the correction is ok.
2. Main power line: Live wire TL and null line N, connect to main power line directly. no switch can be allowed when emergency lighting. the law forbids the switch control emergency circuit.
3 .The wall switch only controls the main power, no function on emergency lighting. The Switch live wire SL and charging live wire TL should be in the same phase.
4. Green light-main power ,Red light-charging , Yellow light-mulfunction;Test: test button
5.Emergency lighting condition,three-color light is all out;
6. Digital circuits, self-test function (monthly inspection, annual inspection), fault or automatic alarm function cause by illegal operation.
7 .You should connect the led lamp and charge the emergency pack before use. In order to avoid emergency lighting function failure.
8 .The environment temperature of Emergency pack ranges from minus ten degrees centigrade to 50 degrees centigrade. High-temperature aging test is forbidded.
9 .Frequently test is prohibited . Each test interval is not less than one minute.
10 .Emergency movement is the core device which controls the battery charge or discharge and start the lighting when under emergency must ensure the wiring is correct. After under normal use, need to discharge once every three months for battery conservation and extend the battery life. Emergency lighting power installed and put into use, need to regularly check, maintain, examine and repair when discover the abnormal condition, or inform the supplier to deal with.
11 .Any problem, contact the manufacturer or supplier pls.
