- Place of Origin:
- Guangdong, China
- Brand Name:
- DF
- Bulb Type:
- LED
- Battery Type:
- Lithium Ion Battery
- Material:
- Cold Rolled Steel Sheet
- Usage:
- emergency lighting
- Certification:
- SAA FCC CE TUV ROHS UN38.83 MSDS
- Specifications:
- 168H-15W90
- Product Name:
- Fire Emergency Lights
- Input Voltage:
- AC 85-265V
- Battery:
- Lithium Ion Battery
- Charge time:
- 20 Hours
- Warranty:
- 15W
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 31X25X13 cm
- Gross weight per batch:
- 9.0 kg
- Package Type:
- 10PCS/BOX
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
- 2
ShenZhen DF led emergency power 15W90min with Lithium Battery Batteries pack
Emergency lighting parameters Product schematic diagram
Emergency power:15W (100% emergency power supply)
Charging Time ≥20 hours
Emergency time ≥90min
Conversion efficiency ≥80%
Power factor ≥90%
Emergency switch time ≤ 1S
Lighting system : continuous
The service life:20000Hours
Temperature range : -10-+50
Humidity range 65%±20%
3,The installation and operation instruction
"(1)—— 1: accordance with writing diagram to connect the circuit in strict. The following lines are connected to each port:
1 —— connect Fire Wire L 2 —— connect the zero line N
3 4 —— Connect light source (suit for LED light source with inside drive).
3 4 —— Connect drive power, and connect light source (suit for LED light source with outside drive)
5 —— Connect switch line. The other side of switch line, Enter the fire wire 1 port. Wall switch only control utility lighting, not affect the emergency lighting
White socket—— connect battery pack
"NO reverse!
2.Emergency power supply can not no-load, whether it is testing emergency lighting function or testing the inverter charging function, must be process under load light source
3. Main power line: fire line L and zero line N, connect to main power line directly, these two lines are forbidden to connect the switch
4. Not control by switch S after the light source start emergency lighting
5: Three-color lamp indicator:
Green : main power indicator; Red: charging; Yellow: falt.
6.At the state of emergency lighting, except to the source lighting, all working indicator lights shall went out.
Third Maintenance
Emergency movement is the core device which controls the battery charge or discharge and start the lighting when under emergency must ensure the wiring is correct. After under normal use, need to discharge once every three months for battery conservation and extend the battery life. Emergency lighting power installed and put into use, need to regularly check, maintain, examine and repair when discover the abnormal condition, or inform the supplier to deal with.
