- Place of Origin:
- Guangdong, China
- Brand Name:
- DF LARES
- Bulb Type:
- LED
- Battery Type:
- lithium-iron battery
- Material:
- Plastic
- Usage:
- emergency lighting
- Certification:
- SAA CE TUV ROHS FCC
- Specifications:
- 268C-F-3.7v2600
- Product Name:
- Fire Emergency Lights
- Input Voltage:
- AC 85-265V
- Battery:
- lithium-iron battery 3.7V2600mAh
- Charge time:
- 24 Hours
- Warranty:
- 3-50W
- SIZE:
- 120*70*30mm
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 47X33X11 cm
- Gross weight per batch:
- 9.5 kg
- Package Type:
- 30 PCS/BOX
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
- 2
panel lamp emergency power kit 3w-50w 3hours CE SAA certificate
1,Emergency Power Supply :DF268C-F 60W emergency output 3W 3hrs
Type of lamp: led 60W Emergency Pack DF268C-F
Input : AC100-280V/50-60HZ Battery Pack LIR battery 3.6V3000mAh
Output: DC20-60V Weight: 300g
Dimension: 120*70*30MM Packing specification: The carton size:39*31*18Cm; 20 pieces/carton
2.Emergency lighting parameters product picture
Emergency power: 3±1W
Charging time: ≥12hS
Duration time: ≥180min
Conversion efficiency ≥80%
Power factor ≥90%
Emergency switching time: ≤ 1S
Lighting system continuous
The service life 20000hS
Temperature range 10- 50℃
Humidity range 65%±20%
3.The installation and operation instruction
1—— Connect LiveWire L+ LED external driver live wire input. This line can set a wall switch S. The wall switch only controls the main power, no function on emergency lighting.
2—— Connect the neutral line N+LED external driver neutral line input
3 light positive
4—— light negative
5—— connect LED driver’s output negative
6—— connect LED driver’s output positive
4.note:
1 .Accordance with writing diagram to connect the circuit in strict,and pay attention to distinguish between the zero line and fire wire.
2 .Forbid connecting line when the mains, please wiring by professional electrician. You should cut off the mains then wiring.
3. Main power line: fire line L and zero line N, connect to main power line directly. no switch can be allowed when emergency lighting. the law forbids the switch control emergency circuit.
4 .The wall switch only controls the main power, no function on emergency lighting.
5 Green light-main power ,Red light-charging , Yellow light-mulfunction;
6 Emergency lighting condition,three-color light is all out;
7 Digital circuits, self-test function (monthly inspection, annual inspection), fault or automatic alarm function cause by illegal operation.
8.Emergency core module is a device which controls the battery charging and discharging, and start lights illumination. Please be sure the wiring is correct before your run our products.
"9.In normal use of electricity, it should discharge once every three months for battery conservation, and to extend battery life.
After the emergency lights power installation into use, there should set a special position for regular inspection and maintenance, and be timely maintenance or notify the supplier when abnormal situation was found."
