Home > Products > LED Emergency Power 518S Australia-SAA Certificate emergency driver 40W-3W-180min
LED Emergency Power 518S Australia-SAA Certificate emergency driver 40W-3W-180min
Click on the image to view the original image
Product: views:5LED Emergency Power 518S Australia-SAA Certificate emergency driver 40W-3W-180min
Branch: DF
Unit Price: Negotiated
Min.Order:
Supply:
Delivery: Shipment within days since the date of payment
Valid until: Long Term
Updated on: 2019-10-16 23:46
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
DF
Bulb Type:
LED
Battery Type:
lithium-iron battery
Material:
Plastic
Usage:
emergency lighting
Certification:
SAA CE TUV ROHS FCC
Specifications:
518S-LIR -3.7v2600
Product Name:
Fire Emergency Lights
Input Voltage:
AC 85-265V
Battery:
lithium-iron battery 3.7V2600mAh
SIZE:
150*40*30mm
Charge time:
12 Hours
Warranty:
2 years
Design life:
3 years

Packaging & Delivery

Selling Units:
Multiple of
Package size per batch:
47X33X15 cm
Gross weight per batch:
9.5 kg
Package Type:
50PCS/BOX
Picture Example:
package-img
Lead Time:
Quantity(Piece)1 - 1000010001 - 100000100001 - 300000>300000
Est. Time(days)2310To be negotiated
Video Description

LED Emergency Power 518S Australia-SAA Certificate emergency driver 40W-3W-180min



 accordance with writing diagram to connect the circuit in strict. The following lines are connected to each po rt:
N—— connect Zero Wire N+ LED external drive zero wire input.
L—— connect the FireWire L+LED external drive fire line input. This line can set a wall switch S. The wall switch only controls the main power, no function on emergency lighting.
(1)——Connect driver output negative terminal
(2)—— Connect driver output positive terminal
(3)——Connect to light source positive terminal
(4)—— Connect to light source negative terminal

1. Diagram wiring, all lines and accessories connected to complete before connecting to the mains test, non-live working.
2: Emergency power supply can not no-load, whether it is testing emergency lighting function or testing the inverter charging function, must be process under load light source
3: Main power line: fire line L and zero line N, connect to main power line directly, these two lines are forbidden to connect the switch
4: Not control by switch S after the light source start emergency lighting
5: Green indicator: main power; Red indicator: charging; yellow: fault.
6: no indicator works in emergency status except emergency lighting
