- Place of Origin:
- Guangdong, China
- Brand Name:
- DF
- Bulb Type:
- LED
- Battery Type:
- lithium-ion battery
- Material:
- Cold Rolled Steel Sheet
- Usage:
- LED lighting
- Certification:
- CB SAA FCC CE TUV ROHS
- Specifications:
- 18W 90mins
- Model Number:
- DF168T
- Light Power Rate:
- Max.25W
- Input:
- AC90-265V/50-60HZ, 5W
- Output:
- 100% emergency power
- Emergency Power:
- 18W90mins
- Battery:
- 11.1V Lithium Ion battery
- Charge time:
- >24 Hours
- Design Life:
- 5 years
- Warranty:
- 2 years
- LED Indicators:
- 1green indicator and test button
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 39X33X13 cm
- Single gross weight:
- 9.0 kg
- Package Type:
- 20PCS/carton
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 100 >100 Est. Time(days) 5 To be negotiated
LED emergency power pack 18W90min led emergency driver 168H with lithium-ion battery
Emergency lighting parameters Product schematic diagram
Emergency power: 18W (100% emergency power supply)
Charging Time ≥20 hours
Emergency time ≥90min
Conversion efficiency ≥80%
Power factor ≥90%
Emergency switch time ≤ 1S
Lighting system : continuous
The service life:20000Hours
Temperature range : -10-+50
Humidity range 65%±20%
3,The installation and operation instruction
AC Input L—— connect port 1.
AC Input N—— connect port 2.
Port 3 connect LED driver input side.
Port 4 connect LED driver input side.
Port 5 Connect switch line. The other side of switch line, parallel the live L; Wall switch only control illuminant , not affect the emergency lighting.
Indicators:
Green indicator: On---Main power on, Off---Main power off;
White socket—— connect battery pack
2.Emergency power supply can not no-load, whether it is testing emergency lighting function or testing the inverter charging function, must be process under load light source
3. Main power line: fire line L and zero line N, connect to main power line directly, these two lines are forbidden to connect the switch
4. Not control by switch S after the light source start emergency lighting
5: LED indicators
6.At the state of emergency lighting, except to the source lighting, all working indicator lights shall went out.
Maintenance
Emergency inverter is the core device which controls the battery charge or discharge. It starts the emergency lighting when there is a power failure. Before the emergency power pack used, please make sure the wiring is correct. After installation, the inverter will automatically go into a charging and discharging cycle. Only when the emergency power is stocked in the warehouse and no wiring, it needs fully charging every 3~6 month to extend the battery span. When emergency power kits installed, it also needs to regularly check, maintain, examine and repair. When there is the abnormal condition, please contact with the supplier to process.
