- Place of Origin:
- SHENZHEN
- Brand Name:
- DF
- Model Number:
- DF268C-F-60-3W180
- Output Power:
- 3-5W
- Output Type:
- Single
- Input Voltage:
- AC100-277V
- Output Frequency:
- 50-60
- Output Current:
- 0.1-1A
- Product Name:
- led emergency driver
- Type:
- df268c-f
- Application:
- Fire safety lighting
- Power factor:
- PF 0.9
- Output:
- DC12---120V
- Lifetime:
- 5 YEARS
- Size:
- 120*70*30mm
- WARRANTY:
- 2 YEARS
- WEIGHT:
- 300G
- Power:
- 3-5W
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 47X33X12 cm
- Gross weight per batch:
- 9.0 kg
- Package Type:
- 30P/BOX
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 10 11 - 500 501 - 1000 >1000 Est. Time(days) 1 2 10 To be negotiated
Automatic LED emergency drive power intelligent 268C-F matching 3-60W universal emergency lighting for 3 hours
Intelligent emergency power supply integration DF268C-F, LED emergency power supply unit. Intelligent LED emergency power supply 8-80W, automatic matching LED lighting for 3 hours
1. Suitable for 3-80W LED panel lights, downlights, ceiling lamps, ceiling lamps and other power-saving emergency lighting;
2. This model is fully automatic emergency power supply device, suitable for LED light source with external constant current source drive.
3, LED emergency power supply contains battery inside, with 3.6V lithium battery as emergency battery;
4, additional mains input cable, output cable and connectors, in line with the needs of the European and American markets, greatly facilitate customer installation and use;
5. This product can reduce power emergency lighting when it is used for emergency lighting. The brightness of the light source is 3-5W during emergency lighting. It is used as an evacuation emergency light to save the cost for the user as much as possible.
6, international line, power reduction emergency lighting, three-color indicator light; slim and ultra-thin installation is convenient.
7. When the mains AC is normally supplied, the inverter will make the emergency lighting battery pack in the charging/standby state; when an accident or other emergency causes the mains AC to be suddenly interrupted, the inverter will be converted into the emergency lighting battery pack DC to continue. Power supply to ensure lighting and safety. Green, red and yellow LED lights show normal main power, charging and fault status respectively. After the battery is fully charged, it automatically enters the maintenance state, compensates for self-discharge, and maintains the performance and use of the battery. Lifetime. Matching batteries of different capacities, it can reach 1-5 hours of emergency lighting time, adapt to the needs of different occasions. Can be used in -20-+50 temperature environment.
8. Connect the circuit strictly according to the wiring diagram, and do not open the cover at will;
9. The user can periodically check the discharge condition of the inverter, that is, cut off the mains power supply, and discharge the battery to automatically terminate;
10, technical parameters:
Input: AC100-265V /50-60Hz Output: DC 20-120V
Power: lamps 10-80W, emergency brightness 3-5W;
Emergency time: 3 hours or according to customer requirements;
Battery: 3.6V lithium battery installed in emergency power supply box
Charging current: 150mA
Length, width and thickness = 120*70*30mm
Weight = 400g (including cable + connector)
