Overview
Quick Details
- Place of Origin:
- Guangdong, China
- Model Number:
- P10
- Brand Name:
- DeKe
- Product name:
- engineering P10 full color display/ P10 LED screen/p10 led module
- Pixel pitch:
- 10mm
- Module size:
- 320*160mm or customized
- Life span:
- 100,000 hours
- Color:
- single: red, blue, green, white, yellow; double; full color
- Waterproof:
- IP65
- Brightness:
- 5000cd/sqm
- Pixel density:
- 10000dots/sqm
- Driving mode:
- static constant current
- Best Viewing Distance:
- 10m
- Display Function:
- ANIMATION
- Screen Dimension:
- 320mm x 160mm
- Pixels:
- 10mm
- Usage:
- Semi-outdoor
- Tube Chip Color:
- red/green/blue
Supply Ability
- Supply Ability:
- 50000 Piece/Pieces per Month Outdoor/indoor engineering P10 full color display
Packaging & Delivery
- Packaging Details
- Export Packing
- Port
- Shenzhen
- Lead Time:
- Within 15~20 days after receive the deposit
Outdoor/indoor P10 full color smd led display module board
Item | Technical Parameters | |||||||||
Pixel Pitch | 10mm | |||||||||
Module Size | 320mm×160mm | |||||||||
Module Pixel | 32×16 | |||||||||
Pixels density | Real :1000 dots/sqm | |||||||||
Pixel form( Optional) | 1or2Amber LEDs | |||||||||
The optimum viewing distance | more than 10m | |||||||||
Wavelength Amber | F625+/-5nm | |||||||||
Cabinet dimension | 960mm×960mm or Customized | |||||||||
Cabinet resolution | 96×96 or Customized | |||||||||
Cabinet weight | 55Kg | |||||||||
Drive mode | Static constant current | |||||||||
Max power consumption | 350W/sqm | |||||||||
Pixel type (Optional) | Real pixel | |||||||||
refresh frequency | 480HZ | |||||||||
Horizontal View Angel | >110 degree | |||||||||
Working Environment | Temp:-20°c~+60°c Humidity: 10%-90% | |||||||||
Working voltage | AC100~120V/AC 220~240V | |||||||||
Life time | 100000 hours Mini | |||||||||
Gray scale | 8 bit amber | |||||||||
Brightness | 5000 cd/sqm | |||||||||
Blind LED lamp rate | <0.00001 | |||||||||
Waterproof level | IP65 |
