- Place of Origin:
- Guangdong, China
- Model Number:
- P4-64x32RGB(Outdoor 8S)
- Brand Name:
- /
- Product name:
- P4-8S outdoor LED display main technical parameters
- Application:
- Outdoor
- Color:
- RGB
- LED chip:
- 1921SMD
- Pixel density:
- 62500 points / m2
- Scanning:
- 1/8 scanning
- Average power consumption:
- <1000W/m2
- Maximum power:
- <= 40W
- Warranty:
- 1-2 Years
- Life span:
- 100000 hours
- Usage:
- OUTDOOR
- Tube Chip Color:
- FULL COLOR
- Display Function:
- Video
- Pixels:
- 4MM
- Screen Dimension:
- 256X128mm
- Supply Ability:
- 100000000000000 Piece/Pieces per Month
- Packaging Details
- Carton
63x30.3x32.2cm-40ps-12KG
- Port
- shenzhen
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 1000 >1000 Est. Time(days) 5 To be negotiated
Product Details
P4-1/8S outdoor LED display main technical parameters
Physical point spacing 4mm
Unit board size 256X128mm
Unit box size:512x512mm
hysical density 62500 points / m2
luminous point colorunit board
resolution 64*32=2048 DOTS
Unit board weight 0.31kg
Cabinet resolution 128*128
Cabinet area 0.262144m2
Standard iron box weight 7.4KG±0.05KG
Product Details
Optimum line of sight 4m ~ 65m
Average power consumption <1000W/m2
Product Details
Control mode: synchronous control
Display card DVI graphics card
Drive mode 1/8 scan
Maximum power <= 40W
Refresh rate >=1920Hz
White balance brightness 5000cd/㎡
Change frequency >=50/60
Brightness adjustment methodBrightness sensing automatic adjustment 16-level adjustable
Product Details
Software manual adjustment: 100 levels adjustable 100
Computer operating system : WIN98,WINXP,WIN2000,etc
Video signal : RF,S-Video,RGB,RGBHV,YUV,YC,COMPOSITION etc
Control System : PCTV card (optional optional) + DVI graphics card + main control card + fiber transmission (optional optional)
Mean time between failures ≧5000 hours
Lifetime 75000~100000 hours
Pixel loss control rate <0.0002 pieces
Project Classification PH4-8SPackage Style Three-in-One LED Package: 1921
Q1. Can I have a sample order for LED modules?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
Q3. Do you have any MOQ limit for led Modules light order?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led Module light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 1-2 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.1%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation during specified inspection time.
