- Place of Origin:
- Shaanxi, China
- Input Voltage(V):
- 2.4
- Lamp Luminous Flux(lm):
- 120
- CRI (Ra>):
- 85
- Working Temperature(℃):
- -40-70
- Working Lifetime(Hour):
- 50000
- IP Rating:
- IP65
- Certification:
- CE
- Warranty(Year):
- 1
- Brand Name:
- DoubleWise
- Model Number:
- DWS305/3NM
- Power Supply:
- Solar
- Light Source::
- Ultre-bright LED
- Lamp Body Material::
- UV resistance PC
- Visible Range::
- 3NM
- Autonomy::
- 100Hrs
- Light Color::
- Red, Green, White,Amber
- Battery Capacity::
- Ni-MH 5Ah/2.4V
- Application::
- Shore beaconHarbor Dredger Tug Boat Tow Yacht
- Certification::
- CE, BV, ISO9001
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 17X17X17 cm
- Single gross weight:
- 1.5 kg
- Package Type:
- 3NM Solar LED Marine Dock Barge Safety Beacon Warning Light Packing detaills are, Each light carton: 170*170*170mm N.W.:0.9kg; G.W.:1.5kg 6pcs light in One carton, total size:540*360*200mm , total G.W.:9kg
- Lead Time:
Quantity(Piece) 1 - 6 >6 Est. Time(days) 12 To be negotiated
Features and benefits
Steady-on and its visibility: 3NM
Solar panel 1.5Wp, replaceable Ni-HM battery 4.8Ah.
Light Output : 112.5°Port/Starboard;135°Stern;225° Masthead.
Turns on at dusk and off at dawn automatically.
Completely self-contained.
Charge under nearly all weather conditions and up to 120 hrs of operating capacity from a full charge.
Individual dome can protect the solar panel and raise its efficiency.
Lens is polycarbonate with anti-UV which is produced by Bayer.
Manufactured to ISO9001:2015 QAS and certified CE.
1.What kind of vessels are suitable for use in solar navigation light?
Using solar navigation lanterns is a best choice for non-powered vessels such as barge,Dredger,Tug or Tow boats etc..
2. Can this lantern easily be turned off when it isn't used for a long period?
Yes,you can easily turn off this lantern by unplugging the battery connecting wire inside it.
We also suggest that you turn off it when it isn't used for a long time.So it is only charged during the day and discharged at night.
3.Is there an attachment that is suitable for a variety of installation methods?
Yes, there is the FlangeBase as follows. For better heat insulation and waterproof, we recommend to use it.
Packaging | ||
Size | 540*360*200mm | |
Weight | Total G.W.:9kg | |
Packaging Details | Each light carton: 170*170*170mm N.W.:0.9kg; G.W.:1.5kg 540*360*200mm carton size contents 6 lights , total G.W.:9kg |
