100w ETFE stronly waterproof semi flexible solar panel for RV BOAT Marine
flexible solar panel
flexible solar panel Feature:
Target buyer is for yacht ,boat ,caravan users;
Light weight and high effciiency of power;
Make travel more easier with enough power backup;
Sunpower cell performance good ;
Warranty:We gurantee that Power output will be at least 95% after 2 years and more than 85% after 5 years.
NO.1 Electrical and Mechanical Characteristics | |||||||
Module | ASF-50WS | ASF-50WL | ASF-100W | ASF-120W | |||
Maximum Power at STC(Pmax) | 50W | 50W | 100W | 120W | |||
Optimum Operating Voltage(Vmp) | 17.7V | 17.7V | 17.7V | 19.9V | |||
Optimum Operating Current(Imp) | 2.82A | 2.82A | 5.65A | 6.03A | |||
Open-Circuit Voltage(Voc) | 21.7V | 21.7V | 21.7V | 24.2V | |||
Short-Circuit Current(Isc) | 3.01A | 3.01A | 6.04A | 6.45A | |||
Module Efficiency | 19.9% | 19.9% | 19.9% | 20.2% | |||
Maximum System Voltage | 600V | 600V | 600V | 600V | |||
Matrix | 4*4 | 2*8 | 4*8 | 4*9 | |||
Size | 555*535*3mm | 1110*285*3mm | 1050*540*3mm | 1175*540*3mm | |||
Weight | 1.20kg | 1.30kg | 2.0kg | 2.25kg | |||
Cables | 2.5mm2 | 2.5mm2 | 2.5mm2 | 2.5mm2 | |||
Cell Efficiency | 22% | 22% | 22% | 23% | |||
Max Power Tolerance | ±10% | ±10% | ±5% | ±5% | |||
STC: Irradiance 1000w/m2,Module temperature 25 °C,AM=1.5 | |||||||
NO.2 Temperature Characteristics | No.3 Maximum Ratings | ||||||
Nominal Operating Cell Temperature(NOCT) | 47±2°C | Operating Module Temperature | -40°C to + 85°C | ||||
Temperature Coefficient of Pmax | -0.38W/°C(-0.38%/°C) | Maximum Series Fuse Rating | 10A | ||||
Temperature Coefficient of Voc | -0.061V°C(-0.28%/°C) |
|
| ||||
Temperature Coefficient of Isc | 3A/°C(0.06%/°C) |
| |||||
