12v 18v flexible mounting roof 80w 100w 120w 200w solar panel racking system
Product Parameter
| Model | FL-TY-055C | FL-TY-056B | FL-TY-056D | FL-TY-080D |
| Solar panel | 18V50W Poly crystalline | 18V80W Poly crystalline | 18V120W Poly crystalline | 18V100W*2 Poly crystalline |
| Controller | 12V10A | 12V10A | 12V10A | 12V20A |
| Inverter | 150W (fixed wave) | 300W (fixed wave) | 300W (fixed wave) | 500W (pure sine wave) |
| Lead acid battery | 12V24AH | 12V38AH | 12V65AH | 12V100AH |
| Led light | 3w*4 | 3w*4 | 3w*4 | 5W*4 |
| PV cables | 5m | 5m | 5m | 5m |
| How much electricity the solar system produce? | ||||
| Charging mode | solar panel | |||
| Charging time | 5.76 hours | 5.76 hours | 6.5 hours | 6.4hours |
| Daily production | 172w-220w | 272w-400w | 408w-648w | 510w-810w |
Average monthly production | 5.16kw-6.6kw | 8.16kw-12kw | 12.24kw-19.44kw | 15.3kw-24.3kw |
Expected annual production | 62.78kw-79.2kw | 99.28kw-146kw | 148.92kw-236.52kw | 186kw-296kw |
| Max. output power | 150W | 300w | 300W | 500W |
| Working mode | AC & DC | |||
| Packing Information | ||||
| Volume(m³) | 0.042 cbm/set | 0.042 cbm/set | 0.051 cbm/set | 0.12 cbm/set |
| G.W.(kg) | 18.2 kg/set | 27.6 kg/set | 36 kg/set | 55 kg/set |
| Quantity/20GP | 619 set | 350 set | 490 set | 350 set |
This solar power kit can supply power for mobile phones, MP3 players,lights, fan,tablet PC, laptop, printer, small TV etc.
than 100w. | ||||
Q1. What advantages does your solar power system have?
A: Solar energy is a locally available renewable and free resource. Electricity produced by PV system is clean and silent. What’s more, the government has up to 40% allowance.
Q2. What factors is related to generated energy of solar power system?
A: in addition to efficiency, another key point is the sunshine. The longer Sunshine time, the more generated energy. it is related to the intensity of sunshine as well, it is less in the morning and at night, more at noon; It is more in Summer and Autumn, less in Winter and Spring.
Q3. What factors will influence the efficiency of solar power system?
A: Components efficiency of the system, weather,direction of the system, the installing angle, etc
