- Item Type:
- Ceiling Lights
- Light Source:
- LED
- Install Style:
- Surface Mounted
- Input Voltage(V):
- 220-240V
- Lamp Luminous Flux(lm):
- 4400
- CRI (Ra>):
- 80
- Working Temperature(℃):
- -20 - 45
- Working Lifetime(Hour):
- 50000
- Lamp Body Material:
- Iron
- IP Rating:
- IP20
- Certification:
- CE, EMC, ETL, LVD, SAA, VDE
- Place of Origin:
- Guangdong, China
- Brand Name:
- OEM
- Model Number:
- C1801
- Application:
- office
- Base Material:
- Steel
- Cover Material:
- Plastic
- Color Temperature(CCT):
- 3000-6000
- LED Light Source:
- SMD2835
- Wattage:
- 20-60W
- Voltage:
- 220-240V
- Material:
- iron
- Luminous efficiency:
- 110lm/w
- Sensor:
- Available
- 3 hrs emergency:
- battery back up
- Suspended mount:
- optional
- Warranty:
- 5 years
- Supply Ability:
- 10000 Piece/Pieces per Month
- Packaging Details
- led light sample
- Port
- zhongshan, shenzhen,guangzhou
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 100 101 - 500 501 - 1000 >1000 Est. Time(days) 30 25 25 To be negotiated
ceiling led batten light
Housing; 0.6mm pressed & folded steel with expoxy powder coated finish
Diffuser: High-diffusion prismatic acrylic material
Driver Cover: 0.4 mm pressed & folded steel sheet with epoxy powder coated finish
Electrical Component:
220-240V/50Hz standard/Dali dimmable/0-10V dimmable led driver
VDE approved terminal block
SMD 2835 0.2W LED Chips
Option
Available for installing with dimmable & emergency kits
Available for installing with sensor
Available for hanging
| Model | Lamp | Lamp size | Package Size |
| C1801-40W/4FT | LED,40W | 1198X126X76MM | 1235X470X160MM |
| C1801-50W/4FT | LED,50W | 1198X126X76MM | 1235X470X160MM |
| C1801-50W/5FT | LED,50W | 1498X126X76MM | 1535X470X160MM |
| C1801-65W/5FT | LED,65W | 1498X126X76MM | 1535X470X160MM |
LIGHT DISTRIBUTION
PACKAGE/WEIGHT
Model No | Size | Master Carton Size | Qty/Carton | Weight |
|
| (LxWxH) |
| (KG)/(LBS) |
C1801-40W/4FT | 4FT | 1235X470X160MM | 5 | 10.90KG |
C1801-50W/4FT | 4FT | 1235X470X160MM | 5 | 1090KG |
C1801-50W/5FT | 5FT | 1535X470X160MM | 5 | 16.00KG |
C1801-65W/5FT | 5FT | 1535X470X160MM | 5 | 16.00KG |
Trade Terms: FOB Zhongshan
Shipping:By sea/by air/by DHL,Fedex,UPS and so on
Ports: Zhongshan, Shenzhen, Yantian, Shekou, Guangzhou
Payment terms:T/T /L/C at sight
Sample: availiable
Production capacity:3000pcs/day
MOQ:100PCS
Sampe lead time:7-10 working days after receipt of payment
Delevery time:30-35 working days after receipt of deposit
Packing:Export carton with foam
Remarks:
1. Halcon’s business principle: honesty, efficiency, sincerity
2. Advantage: designer with over 5 years’ experience + strict control on quality +
direct factory price + excellenct commnication group
